Text version of the page
320
3
D
T
L1
d
T
D
i
2,35 3,0 6,0
Bestseller!
Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de
3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points
Diamond grinding points
shank Ø 6 mm
Vrecom. = 15 - 20 m/s (head-Ø > 10 mm Vmax. = 20 m/s) • max. extension length 0.5 L, shank tolerance = h6, head tolerance = ± 0.2 mm
Diamond grinding points, galvanic
bonding, shank Ø 6 mm
Head dimensions
D x T
Neck dim.
d x L1
Angle Radius
R
Shank Ø x
total length
Grit
size
Order No. Price from
5 pieces
Price from
1 piece
Cylinder Ø 2.0 x 4.0 Ø 1.7 x 20 - - Ø 6 x 60 D 91 0 560 382
Ø 2.0 x 4.0 Ø 1.7 x 20 - - Ø 6 x 60 D 126 0 560 383
Ø 2.0 x 4.0 Ø 1.7 x 20 - - Ø 6 x 60 D 181 0 560 384
Ø 3.0 x 5.0 Ø 2.7 x 20 - - Ø 6 x 60 D 91 0 560 385
Ø 3.0 x 5.0 Ø 2.7 x 20 - - Ø 6 x 60 D 126 0 560 386
Ø 3.0 x 5.0 Ø 2.7 x 20 - - Ø 6 x 60 D 181 0 560 387
Ø 4.0 x 7.0 Ø 3.7 x 20 - - Ø 6 x 60 D 91 0 560 388
Ø 4.0 x 7.0 Ø 3.7 x 20 - - Ø 6 x 60 D 126 0 560 389
Ø 4.0 x 7.0 Ø 3.7 x 20 - - Ø 6 x 60 D 181 0 560 390
Ø 5.0 x 7.0 Ø 4.7 x 20 - - Ø 6 x 60 D 91 0 560 391
Ø 5.0 x 7.0 Ø 4.7 x 20 - - Ø 6 x 60 D 126 0 560 392
Ø 5.0 x 7.0 Ø 4.7 x 20 - - Ø 6 x 60 D 181 0 560 393
Ø 6.0 x 8.0 Ø 5.7 x 20 - - Ø 6 x 60 D 181 0 560 356
Ø 6.0 x 8.0 Ø 5.7 x 20 - - Ø 6 x 60 D 91 0 560 358
Ø 6.0 x 8.0 Ø 5.7 x 20 - - Ø 6 x 60 D 126 0 560 357
Ø 6.0 x 20.0 - - - Ø 6 x 60 D 91 0 560 820
Ø 6.0 x 20.0 - - - Ø 6 x 60 D 126 0 560 819
Ø 6.0 x 20.0 - - - Ø 6 x 60 D 181 0 560 818
Ø 8.0 x 6.0 - - - Ø 6 x 60 D 181 0 560 821
Ø 8.0 x 6.0 - - - Ø 6 x 60 D 91 0 560 823
Ø 8.0 x 6.0 - - - Ø 6 x 60 D 126 0 560 822
Ø 10.0 x 6.0 - - - Ø 6 x 60 D 91 0 560 366
Ø 10.0 x 6.0 - - - Ø 6 x 60 D 126 0 560 365
Ø 10.0 x 6.0 - - - Ø 6 x 60 D 181 0 560 364
Ø 10.0 x 10.0 - - - Ø 6 x 60 D 91 0 560 829
Ø 10.0 x 10.0 - - - Ø 6 x 60 D 126 0 560 828
Ø 10.0 x 10.0 - - - Ø 6 x 60 D 181 0 560 827
Ø 10.0 x 15.0 - - - Ø 6 x 60 D 91 0 560 832
Ø 10.0 x 15.0 - - - Ø 6 x 60 D 126 0 560 831
Ø 10.0 x 15.0 - - - Ø 6 x 60 D 181 0 560 830
Ø 12.0 x 6.0 - - - Ø 6 x 60 D 91 0 560 371
Ø 12.0 x 6.0 - - - Ø 6 x 60 D 126 0 560 370
Ø 12.0 x 6.0 - - - Ø 6 x 60 D 181 0 560 369
All measurements in mm
