318 3 D T L1 d i 3,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Diamond grinding points, solid tungsten carbide shank Ø 3 mm Diamond grinding points, solide tungsten carbide, galvanic bonding, shank Ø 3 mm Head dimensions D x T Neck dimensions d x L1 Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 0.4 x 2.0 Ø 0.3 x 3 Ø 3 x 40 D 54 0 560 051 Ø 0.5 x 2.0 Ø 0.4 x 5 Ø 3 x 40 D 64 0 560 052 Ø 0.6 x 3.0 Ø 0.5 x 5 Ø 3 x 40 D 64 0 560 053 Ø 0.4 x 5 Ø 3 x 40 D 91 0 560 054 Ø 0.7 x 3.0 Ø 0.6 x 5 Ø 3 x 40 D 64 0 560 055 Ø 0.5 x 5 Ø 3 x 40 D 91 0 560 056 Ø 0.8 x 3.0 Ø 0.7 x 6 Ø 3 x 40 D 64 0 560 057 Ø 0.6 x 6 Ø 3 x 40 D 91 0 560 058 Ø 0.9 x 3.0 Ø 0.8 x 10 Ø 3 x 40 D 64 0 560 059 Ø 0.7 x 10 Ø 3 x 40 D 91 0 560 060 Ø 1.0 x 3.0 Ø 0.8 x 10 Ø 3 x 40 D 76 0 560 061 Ø 0.7 x 10 Ø 3 x 40 D 107 0 560 062 Ø 0.7 x 6 Ø 3 x 40 D 151 0 560 063 Ø 1.1 x 3.0 Ø 0.9 x 10 Ø 3 x 40 D 76 0 560 064 Ø 0.8 x 10 Ø 3 x 40 D 107 0 560 065 Ø 0.8 x 10 Ø 3 x 40 D 151 0 560 066 Ø 1.2 x 3.0 Ø 1.0 x 15 Ø 3 x 40 D 76 0 560 067 Ø 0.9 x 10 Ø 3 x 40 D 107 0 560 068 Ø 0.9 x 10 Ø 3 x 40 D 151 0 560 069 Ø 1.3 x 3.0 Ø 1.1 x 15 Ø 3 x 40 D 76 0 560 070 Ø 1.0 x 15 Ø 3 x 40 D 107 0 560 071 Ø 1.0 x 10 Ø 3 x 40 D 151 0 560 072 Ø 1.4 x 3.0 Ø 1.2 x 15 Ø 3 x 40 D 76 0 560 073 Ø 1.1 x 15 Ø 3 x 40 D 107 0 560 074 Ø 1.1 x 15 Ø 3 x 40 D 151 0 560 075 Ø 1.5 x 3.0 Ø 1.3 x 15 Ø 3 x 40 D 76 0 560 076 Ø 1.2 x 15 Ø 3 x 40 D 107 0 560 077 Ø 1.2 x 15 Ø 3 x 40 D 151 0 560 078 Ø 1.6 x 4.0 Ø 1.4 x 15 Ø 3 x 40 D 76 0 560 079 Ø 1.3 x 15 Ø 3 x 40 D 107 0 560 080 Ø 1.3 x 15 Ø 3 x 40 D 151 0 560 081 Ø 1.7 x 4.0 Ø 1.5 x 15 Ø 3 x 40 D 76 0 560 082 Ø 1.4 x 15 Ø 3 x 40 D 107 0 560 083 Ø 1.4 x 15 Ø 3 x 40 D 151 0 560 084 Diamond grinding points, solid tungsten carbide The new diamond grinding points made from solid tungsten carbide convince through their high rigidity and the resulting precise true running. They are available in ascending increments of 1/10 mm with a head diameter from 0.4 to 3.0 mm. All measurements in mm Suitable for every measure! These grinding points are available in increments of 1/10 mm between 0.4 and 3.0 mm diameter. You are sure to find the right one for your application!
