314 3 D T L1 d D d L1 D1 D T T D1 D D T R D T T D1 D d D T L1 T D D T D T D1 D T 2,35 3,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Precision diamond grinding points shank Ø 3 mm Vrecom. = 15 - 20 m/s • max. extension length = 0.5 x L Precision diamond grinding points, galvanic bonding, shank Ø 3 mm Head dimensions D/D1 x T Angle Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 1.6 x 4.6 - Ø 3 x 44.5 D 126 0 560 271 Ø 1.9 x 5.0 - Ø 3 x 44.5 D 126 0 560 272 Ø 2.5 x 5.2 - Ø 3 x 44.5 D 126 0 560 273 Ø 3.5 x 5.8 - Ø 3 x 44.5 D 126 0 560 274 Sphere Ø 1.0 - Ø 3 x 44.5 D 126 0 560 260 Ø 1.8 - Ø 3 x 44.5 D 126 0 560 261 Ø 2.0 - Ø 3 x 44.5 D 126 0 560 262 Ø 2.9 - Ø 3 x 44.5 D 126 0 560 263 Wheel Ø 5.3 x 0.8 - Ø 3 x 44.5 D 126 0 560 277 Ø 5.4 x 2.0 - Ø 3 x 44.5 D 126 0 560 278 Ø 6.4 x 2.0 - Ø 3 x 44.5 D 126 0 560 279 Wheel with front screw Ø 22.0 x 0.3 - Ø 3 x 44.5 D 76 0 560 287 Ø 22.0 x 0.3 - Ø 3 x 44.5 D 107 0 560 288 Cone Ø 1.6 / 1 x 4.6 - Ø 3 x 44.5 D 126 0 560 267 Ø 2.1 / 1.3 x 7.7 - Ø 3 x 44.5 D 126 0 560 268 Ø 2.1 / 1.7 x 4.6 - Ø 3 x 44.5 D 126 0 560 269 Pointed cone Ø 2.5 x 6.9 20° Ø 3 x 44.5 D 126 0 560 281 Ø 5.1 x 4.3 60° Ø 3 x 44.5 D 126 0 560 282 Round cone Ø 3.4 / 2.6 x 9.2 - Ø 3 x 44.5 D 126 0 560 276 Trapeze Ø 1.5 / 1.3 x 1.8 10,7° Ø 3 x 44.5 D 126 0 560 264 Ø 2.3 / 1.9 x 6.2 5,3° Ø 3 x 44.5 D 126 0 560 266 Ø 2.6 / 2.1 x 2.3 10,7° Ø 3 x 44.5 D 126 0 560 265 Ø 3.3 / 2.5 x 9.4 5° Ø 3 x 44.5 D 126 0 560 270 Trapeze, outline coated Ø 6.2 / 3 x 3.1 75° Ø 3 x 44.5 D 126 0 560 283 Ø 8.2 / 3 x 4 75° Ø 3 x 44.5 D 126 0 560 284 Trapeze, front coated Ø 6.4 / 3 x 2.3 75° Ø 3 x 44.5 D 126 0 560 285 Ø 9.4 / 3 x 4.5 75° Ø 3 x 44.5 D 126 0 560 286 Pointed arch Ø 2.2 x 9.0 - Ø 3 x 44.5 D 126 0 560 275 Ø 6.1 x 2.3 - Ø 3 x 44.5 D 126 0 560 280 All measurements in mm
