3 313 D T R T D1 D D T T D1 D d D T L1 D R T R D T R D T D T ƒü ƒý ƒü ƒý ƒü ƒý ƒý ƒü ƒü ƒý ƒü ƒý ƒü ƒý Original DIPROFIL® 2,35 3,0 6,0 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Precision diamond grinding points DIPROFIL® shank Ø 3 mm Vrecom. = 15 - 20 m/s (head-Ø > 10 mm Vmax. = 20 m/s) • max. extension length 25 mm DIPROFIL® diamond grinding points, galvanic bonding, shank Ø 3 mm Head dimensions D/D1 x T Neck dimensions d x L1 Angle Radius Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Pointed arch Ø 1.6 x 7.5 - - 45 Ø 3 x 46 D 151 0 560 644 Ø 1.6 x 10 - - 45 Ø 3 x 46 D 64 0 560 643 -1 Ø 1.6 x 10.0 - - 45 Ø 3 x 46 D 151 0 560 643 Ø 2.4 x 7.5 - - 30 Ø 3 x 46 D 151 0 560 642 Ø 2.4 x 10.0 - - 30 Ø 3 x 46 D 64 0 560 641 -1 Ø 2.4 x 10.0 - - 30 Ø 3 x 46 D 151 0 560 641 Ø 6.0 x 10.0 - - 17 Ø 3 x 49 D 151 0 560 602 Cone Ø 1.6 / 0.9 x 10.0 - 4° - Ø 3 x 46 D 151 0 560 632 Ø 2.1 / 1.4 x 10.0 - 4° - Ø 3 x 46 D 64 0 560 630 -1 Ø 2.1 / 1.4 x 10.0 - 4° - Ø 3 x 46 D 151 0 560 630 Ø 2.6 / 1.75 x 7.0 - 4° - Ø 3 x 46 D 151 0 560 629 Pointed cone Ø 3.1 x 5.0 Ø 1.8 x 7 30° - Ø 3 x 46 D 64 0 560 647 -1 Ø 3.1 x 5.0 Ø 1.8 x 7 30° - Ø 3 x 46 D 151 0 560 647 Ø 7.0 x 10.0 - 30° - Ø 3 x 49 D 151 0 560 612 Ø 8.0 x 8.5 - 45° - Ø 3 x 47 D 151 0 560 607 Ø 8.0 x 6.6 - 60° - Ø 3 x 46 D 151 0 560 610 Ø 8.0 x 3.9 - 90° - Ø 3 x 43 D 151 0 560 609 Round cone Ø 1.3 / 0.7 x 9.0 - 4° - Ø 3 x 46 D 151 0 560 650 Ø 1.6 / 0.8 x 9.0 - 5° - Ø 3 x 46 D 151 0 560 649 Ø 1.9 / 1.1 x 9.0 - 5° - Ø 3 x 46 D 64 0 560 648 -1 Ø 1.9 / 1.1 x 9.0 5° - Ø 3 x 46 D 151 0 560 648 Trapeze Ø 2.4 x 3.0 Ø 1.5 x 7 20° - Ø 3 x 46 D 64 0 560 638 -1 Ø 2.4 x 3.0 Ø 1.5 x 7 20° - Ø 3 x 46 D 151 0 560 638 Ø 6.5 x 10.0 - 15 - Ø 3 x 49 D 151 0 560 608 Trapeze, outline coated Ø 8.0 x 3.0 - 90° - Ø 3 x 42 D 151 0 560 604 Barrel Ø 7.0 x 10.0 - - 10 Ø 3 x 49 D 151 0 560 616 Drop Ø 6.0 x 10.0 - 20° 3.0 Ø 3 x 49 D 151 0 560 615 Round cylinder Ø 6.0 x 10.0 - - 3 Ø 3 x 49 D 151 0 560 614 = also available in a set (see following page)! All measurements in mm
