3
312
D1 D
T
D
T
L1
d
D
d
L1
T
D
D1 D
T
T
D
R
ğ
ƒý
ğ
ƒý
ğ
ƒý
ğ
ƒý
Original
DIPROFIL®
2,35 3,0 6,0
3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points
Precision diamond grinding points DIPROFIL®
shank Ø 3 mm
Vrecom. = 15 - 20 m/s (head-Ø > 10 mm Vmax. = 20 m/s) • max. extension length 25 mm
DIPROFIL® diamond grinding points,
galvanic bonding, shank Ø 3 mm
Head dimensions
D/D1 x T
Neck dimensions
d x L1
Angle
Radius
Shank Ø x
total length
Grit
size
Order No. Price from
5 pieces
Price from
1 piece
Cylinder Ø 0.8 x 4.0 Ø 0.5 x 7 - - Ø 3 x 46 D 107 0 560 671
Ø 1.0 x 4.0 Ø 0.6 x 8 - - Ø 3 x 46 D 107 0 560 672
Ø 1.5 x 4.0 Ø 1.2 x 10 - - Ø 3 x 46 D 107 0 560 673
Ø 2.0 x 5.0 Ø 1.6 x 14 - - Ø 3 x 46 D 64 0 560 674 -1
Ø 2.0 x 5.0 Ø 1.6 x 14 - - Ø 3 x 46 D 151 0 560 674
Ø 2.5 x 5.0 Ø 2.1 x 19 - - Ø 3 x 46 D 151 0 560 675
Ø 2.5 x 7.0 Ø 2.1 x 19 - - Ø 3 x 46 D 151 0 560 628
Ø 3.0 x 5.0 Ø 2.6 x 21 - - Ø 3 x 46 D 64 0 560 676-1
Ø 3.0 x 5.0 Ø 2.6 x 21 Ø 3 x 46 D 151 0 560 676
Ø 3.5 x 5.0 - - - Ø 3 x 50 D 151 0 560 677
Ø 4.0 x 5.0 - - - Ø 3 x 50 D 151 0 560 678
Ø 5.0 x 6.0 - - - Ø 3 x 50 D 151 0 560 680
Ø 6.0 x 6.0 - - - Ø 3 x 50 D 151 0 560 682
Ø 6.0 x 10.0 - - - Ø 3 x 49 D 151 0 560 603
Sphere Ø 1.7 Ø 1 x 5 - - Ø 3 x 46 D 64 0 560 637 -1
Ø 1.7 Ø 1 x 5 - - Ø 3 x 46 D 151 0 560 637
Ø 2.1 Ø 1.3 x 6 - - Ø 3 x 46 D 151 0 560 636
Ø 2.5 Ø 1.5 x 6 - - Ø 3 x 46 D 151 0 560 635
Ø 3 Ø 1.5 x 6 - - Ø 3 x 46 D 64 0 560 634 -1
Ø 3 Ø 1.5 x 6 - - Ø 3 x 46 D 151 0 560 634
Ø 4.1 Ø 1.8 x 7 - - Ø 3 x 46 D 151 0 560 633
Ø 5.0 - - - Ø 3 x 46 D 151 0 560 651
Ø 6.0 - - - Ø 3 x 46 D 151 0 560 601
Lens Ø 4.1 x 1.3 Ø 1.8 x 5 - 60 Ø 3 x 48 D 151 0 560 646
Ø 9.3 x 1.3 - - 75 Ø 3 x 41 D 151 0 560 645
Wheel Ø 7.3 x 0.8 - - - Ø 3 x 40 D 151 0 560 625
Ø 9 / 7 x 0.6 - - - Ø 3 x 40 D 151 0 560 624
Ø 17.2 / 14.6 x 2.4 - - - Ø 3 x 48 D 151 0 560 622
Ø 20 / 12.75 x 1 - - - Ø 3 x 48 D 151 0 560 623
Wheel with front screw Ø 22 / 20 x 0.6 - - - Ø 3 x 48 D 151 0 560 620
Wheel, rounded Ø 5.8 x 2.3 - - 1 Ø 3 x 41 D 151 0 560 627
Ø 9.8 x 3.4 - - 1.5 Ø 3 x 42 D 151 0 560 626
Wheel, front coated Ø 22 / 7 x 0.35 - - - Ø 3 x 48 D 151 0 560 621
All measurements in mm
