310
3
Bestseller!
2,35 3,0
3,0
Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de
3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points
Diamond cut-off discs DIPROFIL®
for shank mounting • shank Ø 2.35 and 3 mm
Diamond point DIATIP
shank Ø 3 mm
Diamond cut-off discs DIPROFIL®,
galvanic bonding
Dimensions
mm
Drilling
dimension
Grit size Order No. Price from
5 pieces
Price from
1 piece
Ø 20 x 0.4 Ø 2.5 D 107 0 560 652
Ø 20 x 0.6 Ø 2.5 D 151 0 560 653
Ø 20 x 0.8 Ø 2.5 D 151 0 560 654
Ø 20 x 1.0 Ø 2.5 D 151 0 560 655
Ø 22 x 0.6 Ø 2.5 D 151 0 560 656
Ø 25 x 0.8 Ø 2.5 D 151 0 560 657
Ø 36 x 1.0 Ø 2.5 D 151 0 560 658
matching shanks Shank
dimensions
Order No. Price from
5 pieces
Price from
1 piece
Hardened stainless steel, thread M 2.5 Ø 2.35 x 37 0 560 665
Ø 3 x 37 0 560 666
Diamond point DIATIP Total
length
Coating
length
Grit
size
Cone
radius
Shank
dimension
Order no. Price
66 50 D 126 2.5° Ø 3 0 560 998
The secret weapon for rib machining. Thanks
to a long coating and small diameter, you can
reach the deepest ribs. Skins to be eroded
are easily torn open, erodible points removed
safely. You therefore use less time with the
following processing steps.
NEW!
Illustration 200 %!
