Diamond and boron nitride tools - joke Technology GmbH - #12

Text version of the page

3 309 D T L1 d D d L1 D1 D T D T T D1 D d D T L1 R D T R D T D1 D T 2,35 3,0 6,0 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Diamond grinding points with metal bonding shank Ø 2.35 mm Cleaning stone Order No. Price In order to keep the cutting edge of the sintered diamond points clean and therefore sharp, the points should be passed over this stone regularly. 0 560 699 Diamond grinding points, metal bonding, shank Ø 2.35 mm Head dimensions D/D1 x T Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 2.7 x 8.0 Ø 2.35 x 44.5 D 107 0 561 230 Round cylinder Ø 2.1 x 7.0 Ø 2.35 x 44.5 D 107 0 561 231 Ø 3.1 x 9.0 Ø 2.35 x 44.5 D 107 0 561 232 Sphere Ø 2.1 Ø 2.35 x 44.5 D 107 0 561 225 Wheel Ø 8.0 x 0.6 Ø 2.35 x 44.5 D 107 0 561 229 Wheel with front screw Ø 8.0 x 0.5 Ø 2.35 x 44.5 D 107 0 561 237 Pointed cone Ø 3.1 x 9.0 Ø 2.35 x 44.5 D 107 0 561 234 Round cone Ø 3.1 x 8.5 Ø 2.35 x 44.5 D 107 0 561 233 Trapeze Ø 1.8 / 1.3 x 2.5 Ø 2.35 x 44.5 D 107 0 561 227 Pointed arch Ø 1.6 x 6.0 Ø 2.35 x 44.5 D 107 0 561 235 Ø 3.1 x 8.0 Ø 2.35 x 44.5 D 107 0 561 236 Diamond grinding point with metal bonding These sintered grinding points are interspersed with diamonds. They convince through their durability and good edge stability. These points achieve fine surfaces on glass, ceramic and other short-chipping materials. Nrecom. = 20,000 – 25,000 rpm All measurements in mm
