469 6 i Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 6. Cleaning systems // 6.1. Cleaning tables Cleaning tables JOKE® BioCleaner NEW! Price Order no. Connection Weight Tank volume Pump output Heating performance Operating temperature Load bearing capacity of work area Device dimensions (W x H x D) Work area (W x H x D) Work height Cleaning tables JOKE® BioCleaner 0 958 000 230 V, 50/60 Hz 55 kg 100 l approx. 4 l/min 1 kW in the heating-up phase, on average 0.1 kW 41 °C 250 kg 1,010 x 1,140 x 785 mm 930 x 250/110 x 545 mm 950 mm Cleaning table JOKE® BioCleaner 930 0 958 020 230 V, 50/60 Hz 45 kg 80 l approx. 4 l/min 0.6 kW in the heating-up phase, on average 0.1 kW 41 °C 100 kg 890 x 1,155 x 750 mm 760 x 20/50 x 560 mm 950 mm Cleaning table JOKE® BioCleaner 760 Accessories JOKE® BioCleaner for model Order no. Price Filter set (Fineness 350 µm) BioCleaner 930 0 958 001 BioCleaner 760 0 958 020-2 Lid BioCleaner 930 0 958 003 BioCleaner 760 0 958 020-1 Cleaning fluid 20 litres 0 958 009 200 litres 0 958 010 filters pollutions and improves the life time of the cleaning fluid. With changeable sieve insert (Fineness 350 ìm), incl. fastening angle and connection (pre-mounted) incl. hinge and fastening material for de-oiling and degrease of metal and plastic workpieces. Cleaning on the basis of water (is not subject to solvent regulation!) optional fine filter (350 ìm) for optimised filtering of the cleaning fluid and consequently an extended period of use Delivery incl. drain system! Energy-saving mode The BioCleaner 930 may be switched to an energy-saving mode with a constant temperature of 30 ºC during shutdown periods (nights, weekends). In this mode, the microorganisms remain active thereby guaranteeing optimum oil and grease degradation.
