478 6 i Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 6. Cleaning systems // 6.2. Ultrasonic cleaners Modular ultrasonic cleaning system JOKE® Flex-Line Built to cope with any cleaning task. Owing to the modular construction, the new JOKE® Flex-Line cleaning devices offer a wide range of configuration possibilities. Ultrasonic cleaning in modern multi-frequency devices forms the basis of this module line with the JOKE® Flex-Line 1. Equipped with an oscillation unit that already results in a cleansing rinsing effect with its up-and-down movements. Consequently, in the combination of ultrasound, oscillation and rinsing, a three-stage cleaning process in two chambers results. Maximum cleaning performance guaranteed! The high flexibility of the JOKE® Flex-Line also makes subsequent additions or adaptations to the cleaning process possible at any time. The structure of the optionally available accessories is also modular. A matching circulating air dryer is available for each size. Likewise, an oil separator, a showering device and a filter-pump unit are available. These components optimise the cleaning result and markedly extend the period of use of the cleaner by optimised filtering. The accessory components can be found on this page (see below) and the Flex Line 1 and 2 systems on the two following pages. Modular ultrasonic cleaning system JOKE® Flex-Line Accessory modules for JOKE® Flex-Line Order No. Price Circulating air dryer on request! for optimum drying of the goods to be cleaned Oil separator on request! longer use of the cleaning fluid during use of demulcent cleaners Showering device on request! additional improved cleaning effect Filter-pump unit on request! We will be pleased to advise you! You will achieve optimum results following comprehensive advice. Please consult Bernd Dörnen in order to individually compile the components of the Flex-Line system in the right combination: Tel. +49 (0) 22 04 / 8 39-0 • Mail: b.doernen@joke.de NEW! Example: Flex-Line 1 with additional showering device and showering station
