392 4 i 2,35 3,0 6,0 m/min Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 4. Chipping tools // 4.1. Milling tools Tungsten carbide milling cutters, shank Ø 2.35 mm Head dimensions mm Shank Ø x total length mm Cut Design Order No. Price from 10 pieces Price from 1 piece Cylinder Ø 1.0 x 4.1 Ø 2.35 x 44.5 Normal Standard 0 517 630 Ø 1.4 x 4.5 Ø 2.35 x 44.5 Normal Standard 0 517 631 Ø 1.6 x 4.5 Ø 2.35 x 44.5 Normal Standard 0 517 632 Ø 2.1 x 5.1 Ø 2.35 x 44.5 Normal Standard 0 517 633 Ø 2.3 x 5.4 Ø 2.35 x 44.5 Normal Standard 0 517 634 Sphere Ø 0.9 x 0.75 Ø 2.35 x 44.5 Normal Standard 0 517 600 Ø 1.0 x 0.8 Ø 2.35 x 44.5 Normal Standard 0 517 601 Ø 1.2 x 1.0 Ø 2.35 x 44.5 Normal Standard 0 517 602 Ø 1.4 x 1.2 Ø 2.35 x 44.5 Normal Standard 0 517 603 Ø 1.6 x 1.4 Ø 2.35 x 44.5 Normal Standard 0 517 604 Ø 1.8 x 1.4 Ø 2.35 x 44.5 Normal Standard 0 517 605 Ø 2.1 x 1.9 Ø 2.35 x 44.5 Normal Standard 0 517 606 Tungsten carbide milling cutters shank Ø 2.35 mm Conversion table – metres per minute (m/min) to revolutions per minute (rpm) Recommended cutting speeds: hardened steels, non-hardened steels, cast steel V = 350 – 700 m/min Stainless steels, titanium, high-alloy steels, nickel V = 450 – 800 m/min Aluminium, plastics, non-ferrous metals V = 500 – 900 m/min Blade diameter/ rotational speed (rpm) m/min 2.0 mm 3.0 mm 6.0 mm 10.0 mm 12.0 mm 16.0 mm 18.0 mm 20.0 mm 25.0 mm 100 15,920 10,600 5,300 3,180 2,650 1,990 1770 1,540 1,270 150 23,880 15,910 7,950 4,770 3,980 2,980 2,650 2,390 1,910 200 31,850 21,210 10,600 6,360 5,300 3,980 3,530 3,180 2,540 250 39,800 26,250 13,260 7,950 6,630 4,970 4,420 3,980 3,180 300 47,770 31,820 15,910 9,550 7,950 5,970 5,300 4,770 3,820 350 55,730 37,130 18,560 11,140 9,280 6,960 6,190 5,570 4,450 400 63,700 42,430 21,210 12,730 10,610 7,960 7,070 6,360 5,090 450 71,650 47,740 23,820 14,320 11,930 8,950 7,960 7,160 5,730 500 79,600 53,040 26,520 15,910 13,260 9,940 8,840 7,950 6,360 550 87,580 58,350 29,170 17,500 14,590 10,940 9,720 8,750 7,000 600 95,540 63,650 31,820 19,090 15,910 11,930 10,610 9,550 7,640 650 103,500 69,000 34,500 20,700 17,250 12,940 11,500 10,350 8,280 700 111,460 74,300 37,150 22,300 18,570 13,930 12,380 11,150 8,900 750 119,420 79,600 39,800 23,880 19,900 14,930 13,270 11,950 9,550 800 127,380 84.900 42,460 25,470 21,230 15,920 14,150 12,740 10,190 850 135,350 90,200 45,110 27,070 22,560 16,920 15,040 13,540 10,830 900 143,310 95,540 47,770 28,660 23,880 17,910 15,920 14,330 11,460
