391 4 nmax 15.000 1/min i 110° Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 4. Chipping tools // 4.1. Milling tools HSS milling cutters, shank Ø 1.6 mm Shape Head dimensions mm Shank dimensions mm Order No. Price Countersunk 110° Ø 2.1 x 1.5 x 12 Ø 1.6 0 009 515 Ø 3.0 x 2.0 x 13 Ø 1.6 0 009 516 Ø 5.0 x 3.0 x 14 Ø 1.6 0 009 517 Tungsten carbide milling cutters with titanium nitride coating shank Ø 1.6 mm Working Ø of the tool 0.7 - 1.0 mm 1.2 - 1.4 mm 1.6 - 1.8 mm 2.1 - 2.3 mm 2.5 - 2.7 mm 2.9 - 3.1 mm 3.3 - 4.0 mm 4.2 - 5.0 mm 5.5 - 7.0 mm 8.0 - 10.0 mm Max. perm. speed 450,000 rpm 450,000 rpm 450,000 rpm 300,000 rpm 160,000 rpm 140,000 rpm 120,000 rpm 95,000 rpm 60,000 rpm 45,000 rpm Recommended rpm 100,000 - 200,000 rpm 70,000 - 220,000 rpm 55,000 - 160,000 rpm 40,000 - 120,000 rpm 35,000 - 110,000 rpm 30,000 - 95,000 rpm 25,000 - 75,000 rpm 15,000 - 60,000 rpm 12,000 - 40,000 rpm 10,000 - 20,000 rpm HSS milling cutters shank Ø 1.6 mm Minimum order amount: 5 pieces! Tungsten carbide milling cutters with titanium nitride coating, shank Ø 1.6 mm Shape Head dimensions mm Shank Ø x total length Cut Order No. Price Cone, round Ø 1.2 x 4.2 Ø 1.6 x 19 Double 0 502 214 Cylinder Ø 1.0 x 4.2 Ø 1.6 x 19 Double 0 502 211 Ø 1.2 x 4.2 Ø 1.6 x 19 Double 0 502 218 Cylinder, round Ø 1.0 x 4.2 Ø 1.6 x 19 Double 0 502 219 Ø 1.2 x 4.2 Ø 1.6 x 19 Double 0 502 213 High speed handpeice P320 • max. speed 320,000 rpm • ideal for all filigree tasks (deburring on steel, stainless steel, glass and plastics) • compact, ergonomic shape • rapid tool change Order No. Price 0 009 901 The ideal implement for filigree tasks:
