388 4 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 4. Chipping tools // 4.1. Milling tools Engraver’s milling cutters in HSS shank Ø 3 mm Engraver’s milling cutters in HSS Ideal for fine working on steel, cast steel, alloyed and unalloyed, and on non-ferrous metals with high resistance to cutting. Cutting speed: Vmax. 60 - 180 m/min Engraver’s milling cutters in HSS, shank Ø 3 mm Shape Head dimensions mm Radius Shank Ø x total length; mm Order No. Price from 10 pieces Price from 1 piece Flame Ø 7.0 x 12 - Ø 3 x 44 0 500 115 Sphere Ø 1.6 x 1.5 - Ø 3 x 38 0 500 148 Ø 2.3 x 2.1 - Ø 3 x 39 0 500 149 Ø 3.2 x 3 - Ø 3 x 40 0 500 150 Ø 4 x 3.8 - Ø 3 x 41 0 500 151 Ø 5 x 4.8 - Ø 3 x 42 0 500 152 Ø 6 x 5.6 - Ø 3 x 43 0 500 153 Ø 7 x 6.7 - Ø 3 x 44 0 500 154 Ø 8 x 7.7 - Ø 3 x 45 0 500 155 Lens Ø 8 x 2 - Ø 3 x 39 0 500 164 Ø 10 x 2.5 - Ø 3 x 40 0 500 165 Ø 12 x 3 - Ø 3 x 40 0 500 166 Ø 14 x 3.5 - Ø 3 x 41 0 500 167 Wheel, flat Ø 6 x 1 - Ø 3 x 38 0 500 172 Ø 8 x 1 - Ø 3 x 38 0 500 173 Ø 10 x 1 - Ø 3 x 38 0 500 174 Wheel, radius Ø 8 x 2 1,1 Ø 3 x 39 0 500 168 Ø 10 x 2.3 1,25 Ø 3 x 39 0 500 169 Ø 12 x 2.6 1,4 Ø 3 x 40 0 500 170 Ø 14 x 3 1,6 Ø 3 x 40 0 500 171 Round cone Ø 7.0 x 10 - Ø 3 x 42 0 500 107 Conical point 35° Ø 1.6 x 2.8 - Ø 3 x 40 0 500 140 Ø 2.3 x 4.0 - Ø 3 x 41 0 500 141 Ø 3.2 x 5.6 - Ø 3 x 43 0 500 142 Ø 4.0 x 7.0 - Ø 3 x 44 0 500 143 Ø 5.0 x 8.7 - Ø 3 x 46 0 500 144 Ø 6.0 x 10.5 - Ø 3 x 46 0 500 145 Ø 7.0 x 12.5 - Ø 3 x 46 0 500 146 Ø 8 x 14 - Ø 3 x 46 0 500 147
