397 4 2,35 3,0 6,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 4. Chipping tools // 4.1. Milling tools Tungsten carbide milling cutters, Shank Ø 3 mm Head dimensions mm Shank Ø x total length Cut Design Order No. Price from 5 pieces Price from 1 piece Cylinder, end cut Ø 2.5 x 11.0 Ø 3 x 50 Double Solid carb. 0 501 802 Ø 3 x 50 Normal Solid carb. 0 503 045 Ø 3 x 75 Double Solid carb. 0 501 803 Ø 3 x 75 Normal Solid carb. 0 503 046 Ø 3.0 Ø 3 x 38 Normal Solid carb. 0 502 441 Ø 3.0 x 12.0 Ø 3 x 38 Diamond Solid carb. 0 501 112 Ø 3.0 x 14.0 Ø 3 x 38 Double Solid carb. 0 501 444 Ø 3 x 38 Normal Solid carb. 0 503 203 Ø 3 x 38 Special-G Solid carb. 0 501 406 Ø 3 x 43 Fine Solid carb. 0 501 342 Ø 3 x 50 Double Solid carb. 0 501 804 Ø 3 x 50 Normal Solid carb. 0 503 047 Ø 3 x 75 Double Solid carb. 0 501 805 Ø 3 x 75 Normal Solid carb. 0 503 048 Ø 6.0 x 7.0 Ø 3 x 37 Fine Standard 0 501 343 Ø 6.0 x 13.0 Ø 3 x 43 Fine Standard 0 501 344 Ø 6.3 x 4.7 Ø 3 x 43 Doble Standard 0 502 551 Ø 3 x 43 Normal Standard 0 503 101 Round cylinder Ø 1.0 x 4.0 Ø 3 x 40 Normal Solid carb. 0 517 348 Ø 1.5 x 4.0 Ø 3 x 40 Normal Solid carb. 0 517 349 Ø 2.0 x 4.0 Ø 3 x 40 Normal Solid carb. 0 517 360 Ø 2.0 x 10.0 Ø 3 x 40 Fine Solid carb. 0 501 331 Ø 2.3 x 11.0 Ø 3 x 38 Special-G Solid carb. 0 501 411 Ø 2.5 x 11.0 Ø 3 x 38 Double Solid carb. 0 503 441 Ø 3 x 38 Normal Solid carb. 0 503 204 Ø 3 x 38 Fine Solid carb. 0 501 334 Ø 3.0 x 14.0 Ø 3 x 38 Double Solid carb. 0 503 442 Ø 3 x 38 Normal Solid carb. 0 503 205 Ø 3 x 38 Fine Solid carb. 0 501 332 Ø 3 x 38 Special-G Solid carb. 0 501 412 Ø 3 x 50 Double Solid carb. 0 503 452 Ø 3 x 50 Normal Solid carb. 0 503 035 Ø 3 x 75 Double Solid carb. 0 503 462 Ø 3 x 75 Normal Solid carb. 0 503 036 Ø 4.0 x 12.7 Ø 3 x 38 Double Standard 0 503 553 Ø 3 x 38 Normal Standard 0 503 214 Ø 5.0 x 12.7 Ø 3 x 38 Double Solid carb. 0 503 552 Ø 3 x 38 Normal Solid carb. 0 503 215 Ø 6.0 x 13.0 Ø 3 x 43 Fine Standard 0 501 333 Ø 6.3 x 12.7 Ø 3 x 50 Double Standard 0 503 551 Ø 3 x 50 Normal Standard 0 503 102 Tungsten carbide milling cutters shank Ø 3 mm Cylinder, end cut (Cont.) • Round cylinder only end cut, both sides for further shapes see following page! NEW! = new product!
