396 4 2,35 3,0 6,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 4. Chipping tools // 4.1. Milling tools Tungsten carbide milling cutters, Shank Ø 3 mm Head dimensions mm Shank Ø x total length Cut Design Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 1.0 x 3.9 Ø 3 x 45 Normal Standard 0 517 423 Ø 1.0 x 4.0 Ø 3 x 40 Normal Solid carb. 0 517 356 Ø 1.5 x 4.0 Ø 3 x 40 Normal Solid carb. 0 517 357 Ø 1.5 x 6.0 Ø 3 x 38 Double Solid carb. 0 501 441 Ø 3 x 38 Fine Solid carb. 0 501 346 Ø 3 x 75 Double Solid carb. 0 501 450 Ø 3 x 75 Normal Solid carb. 0 503 082 Ø 1.6 x 5.0 Ø 3 x 38 Diamond Solid carb. 0 501 100 Ø 2.0 x 4.0 Ø 3 x 40 Normal Solid carb. 0 517 358 Ø 2.1 x 5.1 Ø 3 x 45 Normal Standard 0 517 428 Ø 2.4 x 9.5 Ø 3 x 38 Diamond Solid carb. 0 501 101 Ø 2.5 x 11.0 Ø 3 x 38 Double Solid carb. 0 501 442 Ø 3 x 38 Normal Solid carb. 0 503 096 Ø 3 x 38 Fine Solid carb. 0 501 345 Ø 3 x 75 Double Solid carb. 0 501 452 Ø 3 x 75 Normal Solid carb. 0 503 084 Ø 3.0 x 12.0 Ø 3 x 38 Diamond Solid carb. 0 501 102 Ø 3.0 x 12.7 Ø 3 x 38 Fine Solid carb. 0 501 347 Ø 3.0 x 14.0 Ø 3 x 38 Double Solid carb. 0 501 443 Ø 3 x 38 Normal Solid carb. 0 503 097 Ø 3 x 38 Special-G Solid carb. 0 501 401 Ø 3 x 50 Double Solid carb. 0 501 453 Ø 3 x 50 Normal Solid carb. 0 503 085 Ø 3 x 75 Double Solid carb. 0 501 463 Ø 3 x 75 Normal Solid carb. 0 503 086 Ø 4.0 x 10.7 Ø 3 x 45 Normal Standard 0 517 432 Ø 5.0 x 12.7 Ø 3 x 38 Double Solid carb. 0 501 552 Ø 3 x 38 Normal Solid carb. 0 503 099 Ø 6.3 x 12.7 Ø 3 x 50 Double Standard 0 501 551 Ø 3 x 50 Normal Standard 0 503 100 Cylinder, end cut Ø 1.5 x 6.0 Ø 3 x 38 Double Solid carb. 0 501 446 Ø 3 x 38 Normal Solid carb. 0 503 201 Ø 3 x 50 Double Solid carb. 0 501 800 Ø 3 x 50 Normal Solid carb. 0 503 043 Ø 3 x 75 Double Solid carb. 0 501 801 Ø 3 x 75 Normal Solid carb. 0 503 044 Ø 1.6 x 5.0 Ø 3 x 38 Diamond Solid carb. 0 501 110 Ø 2.0 x 10.0 Ø 3 x 40 Fine Solid carb. 0 501 341 Ø 2.4 x 9.5 Ø 3 x 38 Diamond Solid carb. 0 501 111 Ø 2.5 x 11.0 Ø 3 x 38 Double Solid carb. 0 501 445 Ø 3 x 38 Normal Solid carb. 0 503 202 Ø 3 x 38 Fine Solid carb. 0 501 348 Tungsten carbide milling cutters shank Ø 3 mm Cylinder • Cylinder, end cut for further shapes see following page! NEW! = new product!
