Tungsten carbide milling cutters
(D Conversion table - metres per minute (m/min) to revolutions per minute (rpm)
Blade diameter/ rotational speed (rpm) m/min
m/min
2.0 mm
3.0 mm
6.0 mm
10.0 mm
12.0 mm
16.0 mm
18.0 mm
20.0 mm
25.0 mm
100
15,920
10,600
5,300
3,180
2,650
1,990
1770
1,540
1,270
150
23,880
15,910
7,950
4,770
3,980
2,980
2,650
2,390
1,910
200
31,850
21,210
10,600
6,360
5,300
3,980
3,530
3,180
2,540
250
39,800
26,250
13,260
7,950
6,630
4,970
4,420
3,980
3,180
300
47,770
31,820
15,910
9,550
7,950
5,970
5,300
4,770
3,820
350
55,730
37,130
18,560
11,140
9,280
6,960
6,190
5,570
4,450
400
63,700
42,430
21,210
12,730
10,610
7,960
7,070
6,360
5,090
450
71,650
47,740
23,820
14,320
11,930
8,950
7,960
7,160
5,730
500
79,600
53,040
26,520
15,910
13,260
9,940
8,840
7,950
6,360
550
87,580
58,350
29,170
17,500
14,590
10,940
9,720
8,750
7,000
600
95,540
63,650
31,820
19,090
15,910
11,930
10,610
9,550
7,640
650
103,500
69,000
34,500
20,700
17,250
12,940
11,500
10,350
8,280
700
111,460
74,300
37,150
22,300
18,570
13,930
12,380
11,150
8,900
750
119,420
79,600
39,800
23,880
19,900
14,930
13,270
11,950
9,550
800
127,380
84.900
42,460
25,470
21,230
15,920
14,150
12,740
10,190
850
135,350
90,200
45,110
27,070
22,560
16,920
15,040
13,540
10,830
900
143,310
95,540
47,770
28,660
23,880
17,910
15,920
14,330
11,460
4
Recommended cutting speeds: hardened steels, non-hardened steels, cast steel V = 350 - 700 m/min
Stainless steels, titanium, high-alloy steels, nickel V = 450 - 800 m/min Aluminium, plastics, non-ferrous metals V = 500 - 900 m/min
Tungsten carbide milling cutters
shank 0 2.35 mm
Tungsten carbide milling cutters, shank 0 2.35 mm
Head Dimen­sions mm
Shank 0 x total length mm
Cut
Design
Order No.
Price € from 10 pieces
Price € from 1 piece
Cylinder
0 1.0 x 4.1
0 2.35 x 44.5
Normal
Standard
0 517 630
—--_
0 1.4 x 4.5
0 2.35 x 44.5
Normal
Standard
0 517 631
0 1.6 x 4.5
0 2.35 x 44.5
Normal
Standard
0 517 632
0 2.1 x 5.1
0 2.35 x 44.5
Normal
Standard
0 517 633
NT* H
0 2.3 x 5.4
0 2.35 x 44.5
Normal
Standard
0 517 634
Sphere
0 0.9 x 0.75
0 2.35 x 44.5
Normal
Standard
0 517 600
— _
0 1.0 x 0.8
0 2.35 x 44.5
Normal
Standard
0 517 601
0 1.2 x 1.0
0 2.35 x 44.5
Normal
Standard
0 517 602
0 1.4 x 1.2
0 2.35 x 44.5
Normal
Standard
0 517 603
0 1.6 x 1.4
0 2.35 x 44.5
Normal
Standard
0 517 604
0 1.8 x 1.4
0 2.35 x 44.5
Normal
Standard
0 517 605
0 2.1 x 1.9
0 2.35 x 44.5
Normal
Standard
0 517 606
