492 7 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 7. Blasting systems // 7.1. Fine and pressure blasting units Fine blasting unit mikromat 800 Injection blasting Fine blasting unit mikromat 800 Order No. Price Dimensions working area (W x D x H) approx. 750 x 590 x 450 mm Dimensions (W x D x H) approx. 760 x 870 x 1400 mm Weight approx. 133 kg Supply voltage 230 V, 50/60 Hz Connected load 0.25 kW Loading capacity grid approx. 75 kg Compressed-air connection 1/4“ Compressed-air range 0.5 - 8 bar Air consumption (at 5 bar) with 2.0 mm air nozzle approx. 240 l/min with 2.5 mm air nozzle approx. 380 l/min with 3.5 mm air nozzle approx. 460 l/min Fan output approx. 200 m3/h Filter surface (main filter) 2,0 m2 Lighting 11 W Supplied with: Complete with maintenance-free prefilter unit, blasting gun made from hardened steel Ø 7 mm, including oil/water separator and pressure reducing valve, security switch (no operation when cover open), air-blow off nozzle and blasting gun holder in the blasting chamber, semi-automatic vibration filter cleaning, blasting shot conditioning through maintenance-free stainless steel cyclone unit 0 950 400 mikromat 800 fine blasting unit Efficient application in tool making, repair and production Areas of use • Scale removal after hardening • Smoothing of plastic and die casting moulds, compression moulding dies and embossing dies • Shot peening on wearing parts • Derusting of components • Deburring of metal components after machining (e.g. turning, drilling, milling) and of duroplatic mouldings from injection moulding and mould casting • Cleaning of plastic and rubber moulds, welds and soldered joints • Preparation of surfaces for paint spraying, glueing and electroplating • Matting and brightening (decorative blasting) Optional extras: • Hand turntable, manual Ø 500 mm (Order No. 0 952 015) • Fine blasting unit microblast (Order No. 0 951 110) • Add-on kit for microblast (Order No. 0 951 111) • Afterfilter system (Order No. 0 952 002) • Frequency control (Order No. 0 952 003) Accessories / spares Order No. Price Blasting gun housing 0 952 016 Air nozzle Ø 2.5 mm 0 952 010-1 Air nozzle Ø 3.5 mm 0 952 010 Blasting nozzle Ø 5 mm 0 952 011-1 Blasting nozzle Ø 7 mm 0 952 011 Tungsten carbide blasting nozzle Ø 7 mm 0 952 022 Boron carbide blasting nozzle Ø 7 mm 0 952 018 Gloves (pair), size 10 0 950 097 Glove, left, size 10 0 950 098 Filter cartridge 0 952 019 Glass pane 0 952 048 Plexiglas pane 0 952 047 Illustration similar
