491 7 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 7. Blasting systems // 7.1. Fine and pressure blasting units Double fine blasting unit mikromat 750 DUO Injection blasting Double fine blasting unit mikromat 750 DUO Order No. Price Dimensions working areas (W x D x H) approx. 620 x 500 x 500 mm Dimensions (W x D x H) approx. 1.400 x 900 x 1.650 mm Weight approx. 300 kg Supply voltage 400 V, 50/60 Hz Connected load 0.55 kW Loading capacity grid approx. 180 kg Compressed-air connection 1/2“ Compressed-air range 0.1 - 10 bar Air consumption (at 5 bar) with 2.5 mm air nozzle approx. 275 l/min with 3.5 mm air nozzle approx. 700 l/min Fan output approx. 1000 m3/h Filter surface (main filter) 8 m2 Blasting shot dosing separately adjustable Lighting 11 W per chamber Supplied with: Complete with exhaust air nozzle for the connection of an afterfilter system or an exhaust airpipe, 2 blasting guns with tungsten carbide nozzle Ø 7 mm, 2 safety switches (no operation when cover open), 2 foot switches and water separator 0 952 006 Double fine blasting unit mikromat 750 DUO Proven JOKE® mikromat quality in a double pack. This model combines two blasting chambers in one unit. And even more: The unit consists of two fullyfledge blasting units, which are connected with a filter unit. Up to now, working with two different blasting shots always meant time-consuming cleaning and refilling of the blasting equipment. Thanks to this double blasting unit, both blasting shots in the two blasting chambers are always ready for use. This not only saves time, but also money. Naturally, the unit allows two users to work at the mikromat 750 DUO at the same time. Both systems work independently and separate from each other, so that they can be used in parallel. Optional extras: • Blow-dry gun (Order No. 0 952 023) • Blasting gun holder (Order No. 0 952 039) • Hand turntable, manual Ø 500 mm (Order No. 0 952 015) • Frequency control (Order No. 0 952 003) • Afterfilter system (Order No. 0 952 002) • Semi-autom. filter cleaning (0 952 031) Accessories / spares Order No. Price Dust bag 0 952 037 Blasting gun housing 0 952 016 Air nozzle Ø 2.5 mm 0 952 010-1 Air nozzle Ø 3.5 mm 0 952 010 Blasting nozzle Ø 5 mm 0 952 011-1 Blasting nozzle Ø 7 mm 0 952 011 Tungsten carbide blasting nozzle Ø 7 mm 0 952 022 Boron carbide blasting nozzle Ø 7 mm 0 952 018 Gloves (pair), size 9 0 952 024-1 Gloves (pair), size 10 0 952 024 Glove, left, size 10 0 952 025 Gloves (pair), size 11 0 952 824 Filter cartridge 0 952 012 Glass pane 0 952 034 Plexiglas pane 0 952 035
