490 7 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 7. Blasting systems // 7.1. Fine and pressure blasting units Fine blasting unit mikromat 600 eco Injection blasting Fine blasting unit mikromat 600 eco Order No. Price Dimensions working area (W x D x H) approx. 600 x 450 x 400 mm Dimensions (W x D x H) approx. 700 x 1000 x 1750 mm Weight approx. 150 kg Supply voltage 400 V, 50 Hz Connected load 0.65 / 0.55 kW Loading capacity grid 100 kg Compressed-air connection 1/2“ Compressed-air range 0.1 - 10 bar Air consumption (at 5 bar) with 2.5 mm air nozzle approx. 275 l/min with 3.5 mm air nozzle approx. 700 l/min Fan output approx. 1000 m3/h Filter surface (main filter) 6 m2 Lighting 11 W Supplied with: Complete with exhaust air nozzle for the connection of an afterfilter system or an exhaust air pipe, blasting gun with tungsten carbide nozzle Ø 7 mm, safety switch (no operation when cover open), foot switch and water separator 0 952 000 Feinstrahlgerät mikromat 600 eco Equipment galore within relatively small dimensions at a very attractive price/performance ratio – that is our mikromat 600 eco for versatile use in workshop and factory. Even the standard equipment is comprehensive, but can be precisely further tailored to individual requirements. “Made in Germany”, the unit also fulfils the highest demands in terms of quality in professional industrial use. Optional extras: • Blow-dry gun (Order No. 0 952 023) • Blasting gun holder (Order No. 0 952 039) • Hand turntable, manual Ø 500 mm (Order No. 0 952 015) • Fine blasting unit microblast (Order No. 0 951 110) • Add-on kit for microblast (Order No. 0 951 111) • Frequency control (230 V, 50 Hz) (Order No. 0 952 003) • Afterfilter system (Order No. 0 952 002) • Semi-autom. filter cleaning (0 952 031) The micromat 600 is available immediately as a pressure blasting unit (mikromat 600 POWER on page 495). Accessories / spares Order No. Price Dust bag 0 952 037 Blasting gun housing 0 952 016 Air nozzle Ø 2,5 mm 0 952 010-1 Air nozzle Ø 3,5 mm 0 952 010 Blasting nozzle Ø 5 mm 0 952 011-1 Blasting nozzle Ø 7 mm 0 952 011 Tungsten carbide blasting nozzle Ø 7 mm 0 952 022 Boron carbide blasting nozzle Ø 7 mm 0 952 018 Gloves (pair), size 9 0 952 024-1 Gloves (pair), size 10 0 952 024 Glove, left only, size 10 0 952 025 Glove, (pair), size 11 0 952 824 Filter cartridge 0 952 012 Glass pane 0 952 034 Plexiglas pane 0 952 035
