489 7 Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 7. Blasting systems // 7.1. Fine and pressure blasting units Fine blasting unit mikromat 50 eco Fine blasting unit mikromat 50 eco The new, budget-priced entry level model offering professional quality for workshop and factory. It is highly recommended for deburring, derusting, descaling and removing of lacquer. This unit offers modern technology with many practical features: Highlights: • Low air consumption (max. 400 l/min) • Integrated dust exhaust for perfect visibility during the blasting process • Aluminium infeed door • Large window • Protected lighting for interior space • Adjustable blasting pressure via pressure regulator with water separator • Easy exchange of blasting shot thanks to steep funnel • Blasting shot is processed in a closed loop (i.e. only dust etc. is removed) • Compact, space-saving design • Loading capacity of grid max. 50 kg • High-performance filter cartridge 240 x 600 mm (= 4 m2 filter space) Optional extras: • Blow-dry gun (Order No. 0 952 023) • Fine blasting unit microblast (Order No. 0 951 110) • Add-on kit for microblast (Order No. 0 951 111) • Blasting gun holder (Order No. 0 952 039) Fine blasting unit mikromat 50 eco Order No. Price Dimensions working area (W x D x H) approx. 500 x 450 x 470 mm Dimensions (W x D x H) approx. 705 x 760 x 1520/1860 mm Dimensions viewing window approx. 400 x 280 mm Weight approx. 80 kg Loading capacity grid 50 kg Compressed-air connection 1/4“ (9 mm) Compressed-air range 0 - 10 bar Air consumption max. 400 l/min Lighting 11 W fluorescent lamp Supply voltage 230 V, 50 Hz Supplied with: Tungsten carbide blasting nozzle (bore Ø 7 mm), gloves with sewed-on sleeves (quick-change system), pressure regulator with water separator, safety switch (no blasting shot supplied if cubicle is open) and foot switch to start/stop the blasting process 0 951 100-5 Accessories / spares Order No. Price Dust bag 0 952 037 Blasting gun housing 0 952 016 Air nozzle Ø 2.5 mm 0 952 010-1 Air nozzle Ø 3.5 mm 0 952 010 Blasting nozzle Ø 5 mm 0 952 011-1 Blasting nozzle Ø 7 mm 0 952 011 Tungsten carbide blasting nozzle Ø 7 mm 0 952 022 Boron carbide blasting nozzle Ø 7 mm 0 952 018 Gloves (pair), size 9 0 952 024-1 Gloves (pair), size 10 0 952 024 Glove, left only, size 10 0 952 025 Gloves (pair), size 11 0 952 824-1 Filter cartridge 0 952 012 Glass pane 0 952 026 Plexiglas pane 0 952 027
