495 7 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 7. Blasting systems // 7.1. Fine and pressure blasting units Pressure blasting unit mikromat 600 POWER Order No. Price Dimensions working area (W x D x H) approx. 600 x 450 x 400 mm Dimensions (W x D x H) approx. 860 x 1.000 x 1.850 mm Weight approx. 200 kg Supply voltage 230 V, 50 Hz Fuse 16 A Protection class IP 54 Connected load 600 W Loading capacity grid 100 kg Compressed-air connection 1/2" External air pressure max. 8 bar Compressed-air control range 1 - 8 bar Air consumption (at 5 bar) with Ø 6 mm air nozzle approx. 1.100 l/min Fan output approx. 1.000 m³/h Filter surface (main filter) 8 m² Lighting 11 W Supplied with: with integrated filter unit, fully-automatical filter cleaning, suction (frequency-controlled), afterfilter system, blasting gun with tungsten carbide blasting nozzle Ø 4,5 mm, safety switch (no operation when cover open), foot switch and water separator 0 952 000D Accessories / spares Order No. Price Dust bag 0 952 037 Gloves (pair), size 9 0 952 024-1 Gloves (pair), size 10 0 952 024 Gloves, left only, size 10 0 952 025 Filter cartridge 0 952 012 Glass pane 0 952 034 Plexiglas pane 0 952 035 Pressure-Blasting gun holder 0 952 823-1 Tungsten carbide blasting nozzle Ø 4,5 mm 0 952 822-1 Boron carbide blasting nozzle Ø 4,5 mm 0 952 822-2 Pressure blasting unit mikromat 600 POWER Maybe the most compact pressure blasting unit in the world. Fully equipped. Available straight away exclusively from JOKE®. Equipped with the power of long acceleration: the blasting shot reaches the workpiece from a closed container (pressure tank) at very high velocity through the blasting hose. In comparison to the injector principle, the blasting shot achieves a multiple of the blasting and impact velocity. Pressure blasting is particularly suitable for large surfaces or for removal of stubborn contamination. Very light (e.g. plastic, walnut shells) or heavy, coarsely grained blasting shots (e.g. hard blasting shot) may be used that do not achieve the necessary impact velocity during injection blasting or would require a very long processing time. A filter unit (8 m2 filter area) is incorporated in the unit and is cleaned fully automatically. Likewise included as standard on board is a manual blasting shot control, frequency-controlled suction and an afterfilter module. The blasting shot tank with a capacity of 13 litres is simple to empty using the pivoting mixing valve. The equipment package is rounded off by the Ø 4.5 mm tungsten carbide blasting nozzle, the blasting gun, the ½” water separator and the rapid venting valve with a silencer. Pressure blasting unit mikromat 600 POWER Pressure blasting NEW!
