Text version of the page
| mikromat 1100 eco fine blasting unit | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ► mikromat 1100 eco fine blasting unit Efficient application in tool making, repair and production Areas of use • Scale removal after hardening • Smoothing of plastic and die casting moulds, compression moulding dies and embossing dies • Shot peening on wearing parts • Derusting of components • Deburring of metal components after machining (e.g. turning, drilling, milling) and of duroplatic mouldings from injection moulding and mould casting • Cleaning of plastic and rubber moulds, welds and soldered joints • Preparation of surfaces for paint spraying, glueing and electroplating • Matting and brightening (decorative blasting) Optional extras: • Blow-dry gun (Order No. 0 952 023) • Blasting gun holder (Order No. 0 952 039) • Hand turntable, manual 0 500 mm (Order No. 0 952 015) • Fine blasting unit microblast (Order No. 0 951 110) • Frequency control (Order No. 0 952 003) • Afterfilter system (Order No. 0 952 002) • Semi-autom. filter cleaning (0 952 031) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| mikromat 1100 eco fine blasting unit | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions working area (W x D x H) Dimensions (B x T x H) Height (with open cover) Weight Supply voltage Connected load Loading capacity grid Compressed air connection Compressed air range Air consumption (at 5 bar) with 2.5 mm air nozzle with 3.5 mm air nozzle Fan output Filter surface (main filter) Blasting shot dosing Lighting | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 920x 900x750 mm 1090 x 1300 x 1650 mm 2000 mm 300 kg 400 V, 50 Hz 0.65 kW 180 kg 1/2" 0,1 -10 bar ca. 275 l/min ca. 700 l/min ca. 1000 m3/h 8 m2 separately adjustable 2 x 12 W (energy-saving lamp) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Supplied with: Complete with exhaust air nozzle for the connection of an afterfilter system or an exhaust airpipe, blasting gun with tungsten carbide nozzle 0 7 mm, safety switch (no operation when cover open), foot switch; not supplied with a water separator | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
