Ac. -

lOOHP^^

xp90-100

Model xp90-l 00 Intensifier Pump:

- 90,000 static psi (6,200 bar)

* 75,000 psi (5,200 bar) continuous operating pressure

-1.45 gpm (5.49 Ipm) flow rate ■ Sound insulation package for quiet operation -100 HP high efficiency TEFC electro motor

- Dual intensifier package

* All voltages available

* Maximum Rated Orifice:

-.017" (.43 mm)

WATERJET SYSTEMS

PRECISION PUMPS

30HP

JP55-30

Model iP55-30 Intensifier Pump:

• 60,000 psi (4,100 bar) rated pump

-0.65 gpm (2.5 Ipm) flow rate

• Sound insulation package for quiet operation

• 30 HP high efficiency TEFC electric motor

• Single intensifier package

• All voltages available

• Maximum Rated Orifice:

-.011 in. (.28 mm)

100HP

ÎP55-100

Model ÎP55-100 Intensifier Pump:

• 60,000 psi (4,100 bar) rated pump

- 2.0 gpm (7.6 Ipm) flow rate

• Sound insulation package for quiet operation

• TOO HP high efficiency TEFC electric motor ■ Dual intensifier package

• All voltages available

• Maximum Rated Orifice:

- .020 in. (.51 mm)

50HP

ÎP60-50 V

Model (P60-50 Intensifier Pump:

• 60,000 psi (4,100 bar) rated pump -1.1 gpm (5 Ipm) flow rate

• Sound insulation package for quiet operation! ■ 50 HP high efficiency TEFC electric motor

- Single intensifier package

- All voltages available

• Maximum Rated Orifice:

-.015 in. (.38 mm)

50HP NEW!

xp90-50

Model xp90-50 Intensifier Pump:

• 90,000 static psi (6,200 bar) i • 75,000 psi (5,200 bar) continuous

operating pressure -0,7 gpm (2.61 Ipm) flow rate

• Sound insulation package for quiet operation

• 50 HP high efficiency TEFC electric motor

• Single intensifier package - All voltages available

• Maximum Rated Orifice:

-.011. (.28mm)

150HP

iP55-150

Model ÏP55-150 Intensifier Pump:

• 60,000 psi (4,100 bar) rated pump

-3.25 gpm (12.1 Ipm) flow rate ' Sound insulation package for quiet operation -150 HP high efficiency TEFC electric motor

• Dual intensifier package

* All voltages available ■ Maximum Rated Orifice: -.025 in. (.64 mm)

200HP

ÎP55-200

Model iP55-200 Intensifier Pump: ■ 60,000 psi (4,100 bar) rated pump -4.0 gpm (15.2 Ipm) flow rate

- Sound insulation package for quiet operation

• 200 HP high efficiency TEFC electric motor

- Dual intensifier package

• All voltages available

• Maximum Rated Orifice:

-.028 in. (.71 mm)

75HP

ÎP55-75

Model iP55-75 Intensifier Pump:

• 60,000 psi (4,100 bar) rated pump

-1.5 gpm (5.7 Ipm) flow rate - Sound insulation package for quiet operation

• 75 HP high efficiency TEFC electric motor

• Single intensifier package ■ All voltages available

• Maximum Rated Orifice:

-.018in.(.46 mm)

on Jet Edgm pumps that arm still going strong!
