13

Hold Down Horizontal

BB*JCFAA* Similar to model 70240, except larger in overallsize and capacity. Supplied with a 70947neoprene tipped spindle assembly.• Holding capacity: 500 lbs. max.• Weight: 9 oz. • Handle moves 65
G DE H ° , bar 90
° 17/64" DIA. HOLESFOR 1/4" SCREWS • U-Bar: 1/2" height, 21/64" inside width• Horizontal spindle adjustment: 1 3/8"• Spindle Thread: 5/16-18
PartBarBaseNumberABCDEFGHJTypeType 70250 1 7/81 3/86 5/817/8—1/41/42 3/4U-BarFlange 70255 2 1/81 5/86 5/81—1/21/41/42 3/4U-BarStraight
*Straight base type dimension BB*JCFAA* 70270 70250 This horizontal clamp is available with U-Barconstruction in a flanged or straight base. Supplied with a 70915 neoprene tipped spindle assembly.Both models supplied with a blue vinyl handle.• Holding capacity: 750 lbs. max.• Weight: 1 lb., 8 oz. • Handle moves 55
G DE H ° , bar 90
° • U-Bar: 3/4" height, 7/16" inside width• Horizontal spindle adjustment: 2 1/4"• Spindle Thread: 3/8-16
21/64" DIA. HOLESFOR 5/16" SCREWS PartBarBaseNumberABCDEFGHJTypeType 70270 2 1/21 3/410 1/41 5/81 5/8—5/165/164 1/8U-BarFlange 70275 3 1/162 3/810 1/41 5/8—7/85/165/164 1/8U-BarStraight
*Straight base type dimension For accessories see pages 13.46.For interchangeability with othertoggle clamps, see page 13.70. Phone 800-537-4367 or 216-486-5540 • Fax: 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 13. 37
