| | | SPRING LOADED DEVICES | | |
| | | |
| | | |
| | | Shortie Spring Plungers Heavy Force With Locking Element | | |
| | | Without Locking Element | | |
| | | |
| | | |
| | | Part Number | | |
| | | Thread | | Part Number | | Force, Lbs. | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | Size | Steel | Delrin | | | | | Steel | Delrin | | | | A | Tip | Tip | Initial | Final | B | C | D | Tip | Tip | | | | 6-32 | 26701 | 30301 | .5 | 3.5 | 3/8 | 1/16 | .046 | 26601 | 30201 | | | | 8-32 | 26702 | 30302 | .5 | 4.0 | 1/2 | 3/32 | .070 | 26602 | 30202 | | | | 10-32 | 26703 | 30303 | .5 | 5.0 | 9/16 | 1/8 | .093 | 26603 | 30203 | | | | 1/4-20 | 26704 | 30304 | .5 | 6.0 | 5/8 | 3/16 | .119 | 26604 | 30204 | | | | 5/16-18 | 26705 | 30305 | .5 | 10.0 | 5/8 | 3/16 | .135 | 26605 | 30205 | | | | 3/8-16 | 26706 | 30306 | 1.0 | 12.0 | 11/16 | 3/16 | .186 | 26606 | 30206 | | | | 1/2-13 | 26707 | 30307 | 2.5 | 15.0 | 13/16 | 1/4 | .248 | 26607 | 30207 | | | | 5/8-11 | 26708 | 30308 | 3.5 | 26.0 | 1 1/8 | 5/16 | .310 | 26608 | 30208 | | | | | | | | | | | | Without Locking | | | | Light Force With Locking Element | | | | Element | | | | | Thread | Part Number | Force, Lbs. | | | | Part Number | | | | Size | Steel | Delrin | | | | | | Steel | Delrin | | | | A | Tip | Tip | Initial | Final | B | C | D | Tip | Tip | | | | 6-32 | 27101 | 30701 | .5 | 1.5 | 3/8 | 1/16 | .046 | 27001 | 30601 | | | | 8-32 | 27102 | 30702 | .5 | 2.0 | 1/2 | 3/32 | .070 | 27002 | 30602 | | | | 10-32 | 27103 | 30703 | .3 | 3.0 | 9/16 | 1/8 | .093 | 27003 | 30603 | | | | 1/4-20 | 27104 | 30704 | .3 | 3.5 | 5/8 | 3/16 | .119 | 27004 | 30604 | | | | 5/16-18 | 27105 | 30705 | .5 | 4.5 | 5/8 | 3/16 | .135 | 27005 | 30605 | | | | 3/8-16 | 27106 | 30706 | 1.5 | 7.5 | 11/16 | 3/16 | .186 | 27006 | 30606 | | | | 1/2-13 | 27107 | 30707 | 1.7 | 8.5 | 13/16 | 1/4 | .248 | 27007 | 30607 | | | | 5/8-11 | 27108 | 30708 | 2.0 | 10.5 | 1 1/8 | 5/16 | .310 | 27008 | 30608 | | | | | | | | | | | | | | | | | |
| | | Jergens Feature: | | |
| | | |
| | | Jergens Shortie Spring Plungers are made to the same quality standards as the Solid Drive® *Made with full standard spring plunger stroke in a short body. A screwdriver slot is substituted for the hex drive due to the smaller size. "Carbon Steel body only • Material: Body - Low Carbon Steel, or 303 Stainless Steel Tip - Delrin or Steel • Finish: Black Oxide on Body • Thread: 2A-UNC Available in metric sizes. See next page. Available in FixtureProTM Design Software | | |
| | | |
| | | Plunger tips are color coded to indicate light or heavy force: Silver = Steel Tip, Light Force Black = Steel Tip, Heavy Force White = Delrin Tip, Light Force Blue = Delrin Tip, Heavy Force Specials available, see page 4.10 for Plunger Quote Request worksheet. | | |
| | | |
| | | |
| | | Heavy Force Stainless Steel With Locking Element | | |
| | | Shortie Spring Plungers Stainless Steel (Short Travel) | | |
| | | |
| | | | | | | | | | | | | | | | Thread | Part Number | Force, Lbs. | | | | | | | Size | Stainless | Delrin | | | | | | | | | A | Tip | Tip | Initial | Final | B | C | D | | | | 8-32 | 27602 | 27622 | 1.5 | 4.75 | 7/16 | .052 | .070 | | | | 8-36 | 27604 | 27624 | 1.5 | 4.75 | 7/16 | .052 | .070 | | | | 10-32 | 27606 | 27626 | 1.75 | 6.25 | 15/32 | .065 | .093 | | | | 1/4-20 | 27608 | 27628 | 3.0 | 10.5 | 17/32 | .078 | .119 | | | | 5/16-18 | 27610 | 27630 | 3.75 | 15.5 | 9/16 | .084 | .135 | | | | 3/8-16 | 27612 | 27632 | 4.5 | 18.5 | 5/8 | .110 | .186 | | | | 1/2-13 | 27614 | 27634 | 5.0 | 28.0 | 3/4 | .151 | .248 | | | | Light Force Stainless Steel With Locking Element | | | | Thread | Part Number | Force, Lbs. | | | | | | | Size | Stainless | Delrin | | | | | | | | | A | Tip | Tip | Initial | Final | B | C | D | | | | 8-32 | 27601 | 27621 | .5 | 1.5 | 7/16 | .052 | .070 | | | | 8-36 | 27603 | 27623 | .5 | 1.5 | 7/16 | .052 | .070 | | | | 10-32 | 27605 | 27625 | .75 | 2.5 | 15/32 | .065 | .093 | | | | 1/4-20 | 27607 | 27627 | 1.0 | 3.5 | 17/32 | .078 | .119 | | | | 5/16-18 | 27609 | 27629 | 1.0 | 4.0 | 9/16 | .084 | .135 | | | | 3/8-16 | 27611 | 27631 | 1.5 | 5.0 | 5/8 | .110 | .186 | | | | 1/2-13 | 27613 | 27633 | 1.75 | 5.5 | 3/4 | .151 | .248 | | | | Specials available, see page 4.10 for Plunger Quote Request worksheet. | | | | | | | | | | | | | | | |
| | | |
| | | The slot in the rear of the Shortie Spring Plunger is for insertion. • Material: Body, 303 Stainless Spring, 303 Stainless Nose, Stainless or Delrin • Thread: 2A-UNC | | |
| | | |
| | | |
| | | 4.6 | | |
