TOGGLE CLAMPS 7 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.9 • Solid arm models include a bolt retainer • U-Bar models include 2 flange washers 70240 This medium duty clamp is ideal for limited space applications. It is supplied with a 70926 neoprene tipped spindle assembly. These medium and large capacity clamps have a large clearance area between the bar and the handle when the clamps are in the fully open position. A blue vinyl handle is included. • For 70262 • Holding capacity: 200 lbs. • Weight: 7 oz. • Handle moves 76°, bar 92° • U-Bar: 1/2" height, 1/4" inside width • Horizontal spindle adjustment: 1 21/32" • Spindle Number: 70926 • For 70264 • Holding capacity: 500 lbs. • Weight: 16 oz. • Handle moves 62°, bar 92° • U-Bar: 9/16" height, 11/32" inside width • Horizontal spindle adjustment: 1 13/32" • Spindle Number: 70947 70262 Hold Down Horizontal Part Base Number A B C D E F G H J K M Type 70262 2 15/16 6 15/32 1 1/32 1 3/32 23/32 7/32 3/32 2 3/8 1/4-20 7/32 Flange 70264 2 7/16 1 11/32 7 13/32 1 1/32 1 7/32 13/16 9/32 3/32 2 9/16 5/16-18 1/4 Flange 71010 2 9/16 1 3/16 6 15/32 1 1/32 — 23/32 7/32 3/32 2 3/8 1/4-20 7/32 Straight 71011 2 7/8 1 1/2 7 13/32 1 1/32 — 13/16 9/32 3/32 2 9/16 5/16-18 1/4 Straight Part S.S. Bar Base Number Part No. A B C D E F G H J Type Type 70240 71006 1 1/2 1 5 7/16 1 1/16 7/8 — 3/16 17/64 2 1/4 U-Bar Flange 70245 71007 1 45/64 1 1/4 5 7/16 1 1/16 — 15/32 3/16 17/64 2 1/4 U-Bar Straight 71008 — 1 1/2 1 5 7/16 1 1/16 7/8 — 3/16 17/64 2 1/4 Soild Flange 71009 — 1 45/64 1 1/4 5 7/16 1 1/16 — 15/32 3/16 17/64 2 1/4 Solid Straight *Straight base type dimension A* B* J A B C M DIA. H E G D F M A* B* J F A B C D G H E 13/64 DIA. • Holding capacity: 200 lbs. • Weight: 5 oz. • Handle moves 60°, bar 90° • U-Bar: 1/2" height, 17/64" inside width • Horizontal spindle adjustment: 1 1/4" • Spindle Thread: 1/4-20 For accessories see pages 7.19 For interchangeability with other toggle clamps, see page 7.42 • Solid arm models include a bolt retainer • U-Bar models include 2 flange washers
