7 T O G G L E C L A M P S
www.jergensinc.com
7.8 Jergens, Inc. Jergens Way 15700 S. Waterloo Road Cleveland, Ohio 44110-3898 USA
B
B*
J
C
A
A*
G
D
E
H
F
11/64" x 17/64"
OBLONG HOLES
FOR NO. 8
SCREWS
70210
The small size of this clamp is ideal
for jobs requiring minimal hold down
force. Available in solid or U-Bar
construction. All models are supplied
with 70962 nylon spindle assemblies
and blue vinyl handles.
K
I
*Straight base type dimension
Note: J dimension goes all the way to end of the U-Bar models
This light duty clamp is designed with
a large clearance area between the
bar and handle when the clamps are
in the full open position. A blue vinyl
handle is included. Includes vinyl
coated spindle assembly.
G
B
A
F
D
E
C
J
H
B*
A*
70260
Hold Down Horizontal
Holding capacity: 60 lbs.
Weight: 1 oz.
Handle moves 80°, bar 90°
Solid Bar: 3/32" height, 1/4" wide
U-Bar: 1/4" height, 3/16" inside width
U-Bar horizontal spindle adjustment: 3/8"
Spindle Thread: 8-32
Holding capacity: 150 lbs.
Weight: 3 oz.
Handle moves 60°, bar 90°
U-Bar: 3/8" height, 7/32" inside width
Horizontal spindle adjustment: 1 1/8"
Spindle Thread: 10-32
Part S.S. Bar Base
Number Part No. A B C D E F G H J I K Type Type
70210 3/4 13/32 2 3/4 5/8 5/8 5/32 5/32 11/16 Solid Flange
70211 3/4 13/32 2 3/4 5/8 5/32 5/32 21/32 3/8 1/2 Solid 1/2 Flange-Left
71001 3/4 13/32 2 3/4 5/8 5/32 5/32 21/32 3/8 1/2 Solid 1/2 Flange-Right
70215 15/16 19/32 2 3/4 5/8 11/32 5/32 5/32 11/16 Solid Straight
70230 71002 3/4 5/16 2 21/32 5/8 5/8 5/32 5/32 11/16 U-Bar Flange
70231 3/4 5/16 2 3/4 5/8 5/32 5/32 21/32 3/8 1/2 U-Bar 1/2 Flange-Left
71003 3/4 5/16 2 3/4 5/8 5/32 5/32 21/32 3/8 1/2 U-Bar 1/2 Flange-Right
70235 15/16 1/2 2 21/32 5/8 11/32 5/32 5/32 11/16 U-Bar Straight
For accessories see pages 7.19 For interchangeability
with other toggle clamps, see page 7.42
*Straight base type dimension
Note: J dimension goes all the way to end of the U-Bar models
Part S.S.
Number Part No. A B C D E F G H J Base Type
70260 71004 1 13/32 3/4 4 3/8 17/32 11/16 5/32 1/8 1 5/8 Flange
71005 1 3/4 13/16 4 3/8 17/32 3/8 5/32 1/8 1 5/8 Straight
Solid arm models include a bolt retainer
U-Bar models include 2 flange washers
