TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.7
Hold Down Vertical
This clamp is available with a solid or U-Bar model.
It features both a horizontal and vertical mounting surface.
A neoprene tipped spindle assembly is included with both
models. A bolt retainer is furnished with the solid bar model.
• Holding capacity: 220 lbs. max.
• U-Bar: 5/8" height, 11/32" inside width
• Spindle Thread: 5/16-18
A
B
H
C
K
F
D
E G
Part Bar Wt
Number A B C D E F G H K Type (oz.)
70285 5 1/2 6 1/16 2 3/4 5/8 1 1 3/8 1 1/2 2 1/2 2 U-Bar 15
71037 5 1/2 6 7/16 2 3/4 5/8 1 1 3/8 1 1/2 2 1/2 — Solid 16
• Solid arm models include a bolt retainer
• U-Bar models include 2 flange washers
For accessories see pages 7.19 For interchangeability
with other toggle clamps, see page 7.42
