TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.41
Model HDC6750P
Operating clamping force: 6,750 lbs (mallet
applied), 1,460 lbs (hand applied)
Weight: 3.4 lbs
Supplied complete with: Set screw & nuts.
Mounting base & locknuts
Model HDC4400PL
Operating clamping force: 3,820 lbs
Weight: 1.7 lbs
Supplied complete with: Set screw & nuts
Mounting base & locknuts,
Nominal holding force: 4,500 lbs
Model HDC3300PL
Operating clamping force: 3,370 lbs
Weight: 0.8 lbs
Supplied complete with: Set screw
& nuts, Mounting base & locknuts
Part Applied Handle Clamping Clamping Force Daylight Clamping
Number Force (Hand Push) Force using Mallet Blows Travel Travel
72413 97 lbs 1460 lbs 6750 lbs 0.433 0.157
72414 81 lbs 3370 lbs N/A 0.205 0.087
72415 85 lbs 3820 lbs N/A 0.276 0.118
Part Number
72413
Part Number
72414
Part Number
72415
Heavy Duty Cam Push Clamps
