7 T O G G L E C L A M P S
www.jergensinc.com
7.40 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Model HDC3300P
Operating clamping force:
3,370 lbs (mallet applied),
1,350 lbs (hand applied)
Weight: 0.6 lbs
Supplied complete with:
Set screw & nuts, Mounting
base and locknuts
Model HDC4400P
Operating clamping force:
4500 lbs (mallet applied),
1,460 lbs (hand applied)
Weight: 1.3 lbs
Supplied complete with:
Set screw & nuts
CMB24 Mounting base & locknuts
Model
HDC2600S (Clockwise)
HDC2600SB (Counter Clockwise)
Operating clamping force:
1,350 lbs (hand applied),
2,700 lbs (mallet applied)
Weight: 2 lbs
Supplied complete with: Setscrew & nuts
Part Applied Handle Clamping Clamping Force Daylight Clamping
Number Force (Hand Push) Force using Mallet Blows Travel Travel
72409 85 lbs 1350 lbs 2700 lbs 0.098 0.079
72410 85 lbs 1350 lbs 2700 lbs 0.098 0.079
72411 81 lbs 1350 lbs 3370 lbs 0.205 0.087
72412 85 lbs 1460 lbs 4500 lbs 0.276 0.118
Part Number
72409
72410
Part Number
72411
Part Number
72412
Heavy Duty Cam Swing Clamps
Heavy Duty Cam Push
