TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.39
Model
HDC675S (Clockwise)
HDC675SB (Counter Clockwise)
Operating clamping force: 675 lbs (hand applied)
Weight: 0.4 lbs
Supplied complete with: Set screw & nuts
Model
HDC1800S (Clockwise)
HDC1800SB (Counter Clockwise)
Operating clamping force: 1,120 lbs
(hand applied), 1,800 lbs (mallet applied)
Weight: 0.9 lbs
Supplied complete with: Set screw & nuts
Part Applied Handle Clamping Clamping Force Daylight Clamping
Number Force (Hand Push) Force using Mallet Blows Travel Travel
72405 47 lbs 674 lbs N/A 0.059 0.059
72406 47 lbs 674 lbs N/A 0.059 0.059
72407 81 lbs 1124 lbs 1800 lbs 0.070 0.070
72408 81 lbs 1124 lbs 1800 lbs 0.070 0.070
Part Number
72405
72406
Part Number
72407
72408
Heavy Duty Cam Swing Clamps
