7 T O G G L E C L A M P S
www.jergensinc.com
7.38 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Model HDC8800R (Clockwise)
HDC8800RB (Counter Clockwise)
Operating clamping force: 1,680 lbs (hand applied),
9,000 lbs (mallet applied)
Weight: 1.21 lbs
Model
HDC11000R (Clockwise)
HDC11000RB (Counter Clockwise)
Operating clamping force: 1,900 lbs (hand applied),
11,240 lbs (mallet applied)
Weight: 2.9 lbs
Part Applied Handle Clamping Clamping Force Daylight Clamping
Number Force (Hand Push) Force using Mallet Blows Travel Travel
72401 81 lbs 1686 lbs 8992 lbs 0.236 0.079
72402 81 lbs 1686 lbs 8992 lbs 0.236 0.079
72403 85 lbs 1910 lbs 11240 lbs 0.315 0.100
72404 85 lbs 1910 lbs 11240 lbs 0.315 0.100
Part Number
72401
72402
Part Number
72403
72404
Heavy Duty Cam Clamps
