Jepgens.
www.jergensinc.com
TOGGLE CLAMP CATALOG
Hold Down Vertical
3E
g
k
This clamp is available with a solid or U-Bar model. It features both a horizontal and vertical mounting surface. A neoprene tipped spindle assembly is included with both models. A bolt retainer is furnished with the solid bar model.
• Holding capacity: 220 lbs. max.
• U-Bar: 5/8" height, 11/32" inside width
• Spindle Thread: 5/16-18
Part
Bar
Wt
Number
A
B
C
D
E
F
G
H
K
Type
(oz.)
70285
5 1/2
6 1/16
2 3/4
5/8
1
1 3/8
1 1/2
2 1/2
2
U-Bar
15
71037
5 1/2
6 7/16
2 3/4
5/8
1
1 3/8
1 1/2
2 1/2
—
Solid
16
For accessories see pages 13.46. For interchangeability with other industrial toggle clamps, see page 13.70.
13.34
Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898
