TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.33
Model HDP11000
Plunger: Locks at both extended &
retracted ends of the stroke
Base: Body mounting
Nominal Holding Force: 11,013 lbs
Weight: 13 lbs 6 oz.
Supplied complete with: Setscrew & nut
Model HDP5500
Plunger: Locks at both extended &
retracted ends of the stroke
Base: Body mounting
Nominal Holding Force: 5,507 lbs
Weight: 8 lbs
Supplied complete with: Setscrew & nut
Part Number
72203
Part Number
72204
Heavy-Duty & Long-Handled Push-Pull Clamps
