TOGGLE CLAMPS 7 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.31 Features: These clamps are of exceptionally robust construction featuring cast and machined handles and bases. The clamps are designed with a low plunger height and with the mechanism guarded within the base to avoid finger traps. Models HDP1300, HDP2600, HDP5500, and HDP11000 have handles of normal length for clamping. The long handled ‘L’ versions (HDP1300/L, HDP5500/L, and HDP11000/L) have their handles either to the front or rear of the clamp according to the application and produce high forces which make them suitable for clamping or for light work such as swaging, rivetting, press fitting components, etc. All models are fitted with a comfortable, cushioned PVC handle grip. Heavy-Duty & Long-Handled Push-Pull Clamps Specifications: The bases of all models, and the handles of models HDP1300, HDP2600, HDP5500, and HDP11000 are machined cast iron. The handles of the ‘L’ versions are of steel bar and mount in housings which are either machined steel castings or machined from steel bar. The plungers are of steel, and their precision ground diameter runs in a close-toleranced hole in the base casting. All axles are of hardened steel and run in either the cast iron of the handle, or in the close-toleranced holes of hardened parts. All models are supplied with a steel setscrew. • Low profile handle • Heavy duty link • Ribbed housing povides extra protection against side impact • Locks in both foward and rear position
