7 T O G G L E C L A M P S
www.jergensinc.com
7.30 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Model JCV/155/FF
Arm: The spindle is in a fixed position
Base: Flanged
Nominal Holding Force: 165 lbs.
Weight: 1.3 oz.
Supplied complete with: Setscrew & nuts
Model JCV550/FF
Arm: The spindle is in a fixed position
Base: Flanged
Nominal Holding Force: 550 lbs.
Weight: 9 oz.
Supplied complete with: Setscrew & nuts
Model JCV770/FF
Arm: The spindle is in a fixed position
Base: Flanged
Nominal Holding Force: 770 lbs.
Weight: 1 lb 6 oz.
Supplied complete with: Setscrew & nuts
Part Number
72160
Part Number
72161
Part Number
72162
Vertical Cam Clamps
