TOGGLE CLAMPS 7 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.3 Part Handle Bar Base Number A B C D E F G H J Type Type Type 70330 3 3/4 15/16 2 9/16 1/2 1 1/16 — 1/4 1/4 1 1/16 Vertical Solid Flange 70335 3 15/16 1 1/8 2 9/16 1/2 — 1/4 1/4 1/4 1 1/16 Vertical Solid Straight 70340 2 13/16 15/16 2 9/16 1/2 1 1/16 — 1/4 1/4 1 1/16 Tee Solid Flange 71016 2 13/16 1 1/8 2 9/16 1/2 — 1/4 1/4 1/4 1 1/16 Tee Solid Straight *Straight base type dimension Note: Width of tee handle is 2 9/16" 70330 This clamp has a narrow bar with a stationary spindle that accepts all 1/4-20 diameter spindles. Each clamp is supplied with a 70926 neoprene tipped spindle assembly. The vertical handle type is supplied with a blue vinyl handle. • Holding capacity: 200 lbs. max. • Weight: 6 oz. • Handle moves 60°, bar 117° • Solid Bar: 3/8" height, 7/32" wide • Spindle Thread: 1/4-20 70342 Hold Down Vertical Part Handle Bar Base Number A B C D E F G H J Type Type Type 70342 4 15/16 3 1/2 1 1/16 — 1/4 1/4 1 3/4 Vertical U-Bar Flange 71017 4 1 1/8 3 1/2 — 9/32 1/4 1/4 1 3/4 Vertical U-Bar Straight 71018 2 13/16 1 1/8 3 1/2 — 9/32 1/4 1/4 1 3/4 Tee U-Bar Straight 71019 2 13/16 15/16 3 1/2 1 1/16 — 1/4 1/4 1 3/4 Tee U-Bar Flange *Straight base type dimension Note: Width of tee handle is 2 9/16" • Solid arm models include a bolt retainer • U-Bar models include 2 flange washers B B* A* J F C A G D H E 13/64 DIA. A A L B B* A* J F C A G D H E 13/64 DIA. A A L This vertical clamp is equipped with a 1/4-20 spindle which has a tip, washers, and locknut for easy clamping. A blue vinyl handle is included. Each clamp is supplied with a 70926 vinyl coated spindle assembly with washer. • Holding capacity: 250 lbs. • Weight: 6 oz. • Handle moves 64°, bar 104° • U-Bar: 3/8" height, 1/4" inside width • Horizontal spindle adjustment: 1 1/8" • Spindle Thread: 1/4-20 • Spindle Number: 70926 • Solid arm models include a bolt retainer • U-Bar models include 2 flange washers For accessories see pages 7.19 For interchangeability with other toggle clamps, see page 7.42
