Vertical Cam Clamps
Features:
Cam clamps are similar to vertical clamps but the clamping force
is generated not by a toggle linkage, but by the action of a roller
on a cam.
The cam action allows components of differing thickness to be
clamped without readjustment of the clamping spindle.
Model JCV155/FF can clamp parts with thickness varying by up
to 1/16", and models JCV550/FF and JCV770/FF thickness
varying by up to 5/64".
A comfortable, cushioned PVC handle grip is fitted to all three
models of cam clamp.
Specifications:
The main components are of zinc plated and passivated steel,
the cam and its roller being case hardened to resist wear.
Rivets are of stainless steel, which burnishes and work-hardens
with use, the rivets of models JCV550/FF and JCV770/FF rotating
in hardened bushes. The setscrews are made of steel.
