7 T O G G L E C L A M P S
www.jergensinc.com
7.28 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
HDV5200 Series Accessories
Part No. 72170
Handle: For welding at the desired angle
to HDV5200/WW & HDV5200/SW
Weight: 10.3 oz.
Part No. 72171
Grip: To fit Part No. 72170 handle
Weight: 4 oz.
Part No. 72172
Arm: For extending the stub
arms of HDV5200/WW & HDV5200/SW
Weight: 1 lb 8 oz.
Part No. 72173
Base: For bolt mounting
HDV5200/WW & HDV5200/SW
Weight: 7 oz.
Model HDV5200/FA
Arm: The spindle is in a fixed position
Base: Flanged
Nominal Holding Force: 5,286 lbs
Weight: 9 lbs.
Supplied complete with: Setscrew & nuts
See below for accessories and handles.
Part Number
72114
Hold Down Vertical
