TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.27
Model HDV5200/SW
Arm: Stub nose for welded extensions
Base: Straight
Nominal Holding Force: 5,291 lbs.
Weight: 7 lbs 1 oz.
See “Features and Installation Information”
on page 7.20 for Installation Instructions.
See page 7.28 for accessories and handles.
Model HDV5200/SS
Arm: Solid arm
Base: Straight
Nominal Holding Force: 5,286 lbs.
Weight: 8 lbs 3 oz.
Supplied complete with: Spindle retainer,
Setscrew & nuts
See page 7.28 for accessories and handles.
Model HDV5200/WW
Arm: Stub nose for welded extensions
Base: Swivel for welding in the desired position
Nominal Holding Force: 5,291 lbs.
Weight: 6 lbs 4 oz.
See “Features and Installation Information”
on page 7.20 for Installation Instructions.
See page 7.28 for accessories and handles.
Part Number
72123
Part Number
72112
Part Number
72113
Hold Down Vertical
