7 T O G G L E C L A M P S
www.jergensinc.com
7.26 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Model HDV2600/FA
Arm: The spindle is in a fixed position
Base: Flanged
Nominal Holding Force: 2,646 lbs.
Weight: 4 lbs 4 oz.
Supplied complete with: Setscrew & nuts
See below for accessories and handles.
HDV2600 Series Accessories
Part No. 72150
Handle: For welding at the desired
angle to HDV2600/WW & HDV2600/SW
Weight: 8 oz.
Part No. 72151
Grip: To fit Part No. 72150 handle
Weight: 0.3 oz.
Part No. 72152
Arm: For extending the stub
arms of HDV2600/WW & HDV2600/SW
Weight: 11 oz.
Part No. 72153
Base: For bolt mounting
HDV2600/WW & HDV2600/SW
Weight: 4 oz.
Part Number
72111
Hold Down Vertical
