TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.25
Model HDV2600/WW
Arm: Stub nose for welded extensions
Base: Swivel for welding in the desired position
Nominal Holding Force: 2,646 lbs.
Weight: 2 lbs 10 oz.
See “Features and Installation Information” on
page 7.20 for Installation Instructions.
See page 7.26 for accessories and handles.
Model HDV2600/SW
Arm: Stub nose for welded extensions
Base: Straight
Nominal Holding Force: 2,646 lbs.
Weight: 3 lbs 2 oz.
See “Features and Installation Information” on
page 7.20 for Installation Instructions.
See page 7.26 for accessories and handles.
Model HDV2600/SS
Arm: Solid arm
Base: Straight
Nominal Holding Force: 2,646 lbs.
Weight: 4 lbs.
Supplied complete with: Spindle retainer,
Setscrew & nuts
See page 7.26 for accessories and handles.
Part Number
72122
Part Number
72109
Part Number
72110
Hold Down Vertical
