7 T O G G L E C L A M P S www.jergensinc.com 7.24 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Model HDV1500/SS Arm: Solid arm Base: Straight Nominal Holding Force: 1,543 lbs. Weight: 2 lbs 5 oz. Supplied complete with: Spindle retainer, Setscrew & nuts See below for accessories and handles. Model HDV1500/FA Arm: The spindle is in a fixed position Base: Flanged Nominal Holding Force: 1,543 lbs. Weight: 2 lbs 9 oz. Supplied complete with: Setscrew & nuts See below for accessories and handles. HDV1500 Series Accessories Part No. 72140 Handle: For welding at the desired angle to HDV1500/WW & HDV1500/SW Weight: 5.3 oz. Part No. 72141 Grip: To fit Part No. 72140 handle Weight: 0.3 oz. Part No. 72142 Arm: For extending the stub arms of HDV1500/WW & HDV1500/SW Weight: 5.5 oz. Part No. 72143 Base: For bolt mounting VHDV1500/WW & HDV1500/SW Weight: 3 oz. Hold Down Vertical Part Number 72108 Part Number 72107
