TOGGLE CLAMPS 7 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.23 HDV660 Series Accessories Part No. 72130 Handle: For welding at the desired angle to HDV660/WW & HDV660/SW Weight: 2 oz. Part No. 72131 Grip: To fit Part No. 72130 handle Weight: 0.5 oz. Part No. 72132 Arm: For extending the stub arms of HDV660/WW & HDV660/SW Weight: 3 oz. Part No. 72133 Base: For bolt mounting HDV660/WW & HDV660/SW Weight: 2 oz. Model HDV1500/WW Arm: Stub nose for welded extensions Base: Swivel for welding in the desired position Nominal Holding Force: 1,543 lbs. Weight: 1lb 7 oz. See “Features and Installation Information” on page 7.20 for installation instructions See page 7.24 for accessories and handles. Model HDV1500/SW Arm: Stub nose for welded extensions Base: Straight Nominal Holding Force: 1,543 lbs. Weight: 1lb 9 oz. See “Features and Installation Information” on page 7.20 for installation instructions See page 7.24 for accessories and handles. Hold Down Vertical Part Number 72121 Part Number 72106
