7 T O G G L E C L A M P S
www.jergensinc.com
7.22 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Model HDV660/SA
Arm: The spindle is adjustable along the arm
Base: Straight
Nominal Holding Force: 660 lbs.
Weight: 9 oz.
Supplied complete with: Set screw & nuts,
Flanged washer
See page 7.23 for accessories and handles.
Model HDV660/FA
Arm: The spindle is adjustable along the arm
Base: Flanged
Nominal Holding Force: 660 lbs.
Weight: 9 oz.
Supplied complete with: Set screw & nuts,
Flanged washer
See page 7.23 for accessories and handles.
Model HDV660/FA2
Arm: The spindle is adjustable along the arm
Base: Flanged
Nominal Holding Force: 660 lbs.
Weight: 9 oz.
Supplied complete with: Set screw & nuts,
Flanged washer
See page 7.23 for accessories and handles.
Hold Down Vertical
Part Number
72103
Part Number
72104
Part Number
72105
