TOGGLE CLAMPS 7
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.21
Model HDV660/WW
Arm: Stub nose for welded extension
Base: Swivel for welding in the desired position
Nominal Holding Force: 660 lbs.
Weight: 6 oz.
See “Features and Installation Information” on
page 7.20 for Installation Instructions.
See page 7.23 for accessories and handles.
Model HDV660/SW
Arm: Stub nose for welded extension
Base: Straight
Nominal Holding Force: 660 lbs.
Weight: 6 oz.
See “Features and Installation Information” on
page 7.20 for Installation Instructions.
See page 7.23 for accessories and handles.
Model HDV660/FW
Arm: Stub nose for welded extension
Base: Flanged
Nominal Holding Force: 660 lbs.
Weight: 7 oz.
See page 7.23 for accessories and handles.
Hold Down Vertical
Part Number
72120
Part Number
72101
Part Number
72102
