7 T O G G L E C L A M P S www.jergensinc.com 7.2 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA 70310 This light duty U-Bar clamp accepts all 8-32 diameter spindles. It is supplied with a 70963 vinyl coated spindle assembly and washers. The vertical handle type is supplied with a blue vinyl handle. • Holding capacity: 100 lbs. max. • Weight: 2.5 oz. • Handle moves 62°, bar 116° • U-Bar: 5/16" height, 3/16" inside width • Horizontal spindle adjustment: 11/16" • Spindle Thread: 8-32 For accessories see pages 7.19. For interchangeability with other toggle clamps, see page 7.42 Part S.S. Number Part No. A B C D E F G 70280 71015 1 13/32 17/32 2 1/4 17/32 5/8 1/4 1 1/32 B G F D A E C Note: Width of tee handle is 1 1/16" 70280 3/16" DIA. HOLES FOR 10-32 SCREWS Hold Down Vertical Part S.S. Handle Bar Base Number Part No. A B C D E F G H J Type Type Type 70310 71012 2 7/8 5/8 2 1/8 5/8 15/16 — 3/16 3/16 1 Vertical U-Bar Flange 70315 71013 3 1/16 7/8 2 1/8 5/8 — 3/16 3/16 3/16 1 Vertical U-Bar Straight 70320 — 2 1/4 5/8 2 1/8 5/8 15/16 — 3/16 3/16 1 Tee U-Bar Flange 71014 — 2 11/16 7/8 2 1/8 5/8 — 3/16 3/16 3/16 1 Tee U-Bar Straight *Straight base type dimension Note: Width of tee handle is 1 5/8" • U-Bar models include 2 flange washers B* A* C F J B A G D H E 11/64 DIA. A A* L This small compact clamp is equipped with a blue vinyl T-shaped grip handle; ideal for moderate to light duty clamping. It is supplied with a 70917 vinyl coated spindle assembly with washer. • Holding capacity: 150 lbs. • Weight: 2 oz. • Handle moves 175°, bar 92° • U-Bar: 5/16" height, 7/32" inside width • Horizontal spindle adjustment: 5/8" • Spindle Thread: 10-32 • Spindle Number: 70917
