7 T O G G L E C L A M P S
www.jergensinc.com
7.18 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
These forged steel, squeeze
action, plier clamps can be used
in a wide range of applications.
Ideal for clamping, fixturing,
holding, processing, or positioning.
All models are supplied with
spindle assemblies.
70730
Supplied with 70945
Spindle Assembly
70720
Supplied with 70946 Spindle Assembly
71050 Supplied with 2 Spindle Assemblies
(Not Shown)
70710
Supplied with 70927 Spindle Assembly
71049 Supplied with 2 Spindle Assemblies
(Not Shown)
70745 (not shown)
Supplied with (2) 70912
Spindle Assembly
70740
Supplied with 70913
Spindle Assembly
70750
Supplied with 70913 and 70914
Spindle Assemblies
Note: F dimension will be less if spindle and locknut are used.
Squeeze Action — Forged Jaws
2 Spindle Holding
Part Part Capacity Spindle Trigger Wt.
Number Number A B C D E F (lbs.) Type Release (oz.)
70710 71049 1 15/16 2 1/16 4 1/2 1 1/8 1/4-20 1 200 Standard No 5
70720 71050 1 7/8 2 13/16 6 1 3/4 5/16-18 1 1/4 350 Standard No 8
70730 — 2 11/16 2 7/8 8 1/16 2 9/32 5/16-18 1/2 700 Standard Yes 16
70740 70745 2 11/16 4 1/4 8 1/2 2 3/4 3/8-16 1 3/4 700 Standard Yes 19
70750 — 2 11/16 4 3/4 8 1/2 2 3/4 3/8-16 3 700 Standard Yes 22
B
D
C
A
E - SPINDLE THREAD
F
2 Spindle Version
