TOGGLE CLAMPS 7 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.15 70850 Same construction as 70810 with three times the holding capacity. Our most powerful straight line action toggle clamp. A blue vinyl handle is included. • Holding capacity: 1500 lbs. • Weight: 3 lb. • Plunger travel: 2 11/32" • Plunger tapped: 1/2-13 X 1 1/2" deep 11/32" DIA. HOLES FOR 5/16" SCREWS B J C G D E H Part Number B C D E G H J 70850 1 3/4 9 1/2 2 2 3/8 3/8 4 5/8 This light duty clamp is equipped with an 8-32 tapped plunger. A blue vinyl handle is included. • Holding capacity: 90 lbs. • Weight: 1.5 oz. • Plunger travel: 5/8" • Plunger tapped: 8-32 X 15/32" deep Part Number A B C D F G H I J K L M N O 70818 1 7/32 2 21/32 1 1/16 1/2 15/32 1/4 7/32 5/16 5/8 3/32 1 11/32 13/16 1 9/32 7/16 B 3/16 DIA. HOLES FOR 10-32 SCREWS L G O H I J D A M N K F J C 70818 3/16" DIA. HOLES FOR 10-32 SCREWS Straight Line For accessories see pages 7.19 For interchangeability with other toggle clamps, see page 7.42
