7 T O G G L E C L A M P S
www.jergensinc.com
7.14 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
70830
MOUNTING
HOLES
B
J
C
G
D
E
H
Part Mounting
Number B C D E G H J Holes
70810 1 4 3/4 1 3/8 1 5/8 5/16 5/16 2 1/4 9/32
70815 1 4 3/4 1 7/16 1 5/16 5/16 5/16 2 1/4 7/32
70810
• Holding capacity: 850 lbs.
• Weight: 1 lb., 4 oz.
• Plunger travel: 1 5/8"
• Plunger tapped: 3/8-16 X 1 1/8" deep
• Holding capacity: 500 lbs.
• Weight: 14 oz.
• Plunger travel: 1 3/16"
• Plunger tapped: 5/16-18 X 1 1/8" deep
11/32" DIA.
HOLES
FOR 5/16"
SCREWS
B
J
C
G
D
E
H
Straight Line
This straight-line extra heavy duty
clamp is constructed of malleable
iron castings and cold rolled steel.
The pivot joints are stainless steel.
The mounting base is precision
machined for flatness. A blue vinyl
handle is included.
Same construction as 70810
with larger capacity. The base
has 11/32" diameter holes
for 5/16" screws. A blue vinyl
handle is included.
Part
Number B C D E G H J
70830 1 1/4 6 1/4 1 5/8 1 5/8 5/16 5/16 3
For accessories see pages 7.19 For interchangeability with other
toggle clamps, see page 7.42
