TOGGLE CLAMPS 7 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 7.13 Vertical Pull Action This clamp is for vertical locking applications, where it is preferable to mount the clamp on a lid. The U-bolt allows for easy adjustment and provide a positive connection with the latch plate (included). • Handle moves 145° A B I H E M G D F J M DIA. THREAD Part U-Bolt Range U-Bolt Range Number A B C D E F G H I J M 71041 1 5/8 1-1 7/8 15/16 1/2 7/8 7/16 1/4 1/4 3/16 3/16-1 3/32 7/32 71042 2 7/16 1 5/16-2 13/32 1 7/32 3/4 1 1/8 9/16 5/16 3/8 1/4 9/32-1 3/8 1/4 70565 3 7/32 1 25/32-3 3/16 1 21/32 1/4 19/32 3/4 3/8 1/2 5/16 11/32-1 25/32 11/32 Part Thread Holding Wt. Number Size Capacity (lbs) (oz.) 71041 M4 x 0.7 305 4 71042 M6 x 1.0 550 11 70565 M8 x 1.25 990 25 For accessories see pages 7.19 For interchangeability with other toggle clamps, see page 7.42
